Inheritance diagram for QCPLayoutElement:

Collaboration diagram for QCPLayoutElement:

Public Types
enum	UpdatePhase { upPreparation, upMargins, upLayout }

Public Member Functions
	QCPLayoutElement (QCustomPlot *parentPlot=0)

virtual	~QCPLayoutElement ()

QCPLayout *	layout () const

QRect	rect () const

QRect	outerRect () const

QMargins	margins () const

QMargins	minimumMargins () const

QCP::MarginSides	autoMargins () const

QSize	minimumSize () const

QSize	maximumSize () const

QCPMarginGroup *	marginGroup (QCP::MarginSide side) const

QHash< QCP::MarginSide, QCPMarginGroup * >	marginGroups () const

void	setOuterRect (const QRect &rect)

void	setMargins (const QMargins &margins)

void	setMinimumMargins (const QMargins &margins)

void	setAutoMargins (QCP::MarginSides sides)

void	setMinimumSize (const QSize &size)

void	setMinimumSize (int width, int height)

void	setMaximumSize (const QSize &size)

void	setMaximumSize (int width, int height)

void	setMarginGroup (QCP::MarginSides sides, QCPMarginGroup *group)

virtual void	update (UpdatePhase phase)

virtual QSize	minimumSizeHint () const

virtual QSize	maximumSizeHint () const

virtual QList< QCPLayoutElement * >	elements (bool recursive) const

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Protected Member Functions
virtual int	calculateAutoMargin (QCP::MarginSide side)

virtual void	mousePressEvent (QMouseEvent *event)

virtual void	mouseMoveEvent (QMouseEvent *event)

virtual void	mouseReleaseEvent (QMouseEvent *event)

virtual void	mouseDoubleClickEvent (QMouseEvent *event)

virtual void	wheelEvent (QWheelEvent *event)

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	draw (QCPPainter *painter)

virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

Protected Member Functions inherited from QCPLayerable
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QCPLayout *	mParentLayout

QSize	mMinimumSize

QSize	mMaximumSize

QRect	mRect

QRect	mOuterRect

QMargins	mMargins

QMargins	mMinimumMargins

QCP::MarginSides	mAutoMargins

QHash< QCP::MarginSide, QCPMarginGroup * >	mMarginGroups

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Friends
class	QCustomPlot

class	QCPLayout

class	QCPMarginGroup

Additional Inherited Members
Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Detailed Description

The abstract base class for all objects that form the layout system.

This is an abstract base class. As such, it can't be instantiated directly, rather use one of its subclasses.

A Layout element is a rectangular object which can be placed in layouts. It has an outer rect (QCPLayoutElement::outerRect) and an inner rect (QCPLayoutElement::rect). The difference between outer and inner rect is called its margin. The margin can either be set to automatic or manual (setAutoMargins) on a per-side basis. If a side is set to manual, that margin can be set explicitly with setMargins and will stay fixed at that value. If it's set to automatic, the layout element subclass will control the value itself (via calculateAutoMargin).

Layout elements can be placed in layouts (base class QCPLayout) like QCPLayoutGrid. The top level layout is reachable via QCustomPlot::plotLayout, and is a QCPLayoutGrid. Since QCPLayout itself derives from QCPLayoutElement, layouts can be nested.

Thus in QCustomPlot one can divide layout elements into two categories: The ones that are invisible by themselves, because they don't draw anything. Their only purpose is to manage the position and size of other layout elements. This category of layout elements usually use QCPLayout as base class. Then there is the category of layout elements which actually draw something. For example, QCPAxisRect, QCPLegend and QCPPlotTitle are of this category. This does not necessarily mean that the latter category can't have child layout elements. QCPLegend for instance, actually derives from QCPLayoutGrid and the individual legend items are child layout elements in the grid layout.

Definition at line 629 of file qcustomplot.h.

Member Enumeration Documentation

enum UpdatePhase

Defines the phases of the update process, that happens just before a replot. At each phase, update is called with the according UpdatePhase value.

Enumerator
upPreparation	Phase used for any type of preparation that needs to be done before margin calculation and layout.
upMargins	Phase in which the margins are calculated and set.
upLayout	Final phase in which the layout system places the rects of the elements.

Definition at line 646 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPLayoutElement ( QCustomPlot * parentPlot = 0 )

explicit

Creates an instance of QCPLayoutElement and sets default values.

Definition at line 1722 of file qcustomplot.cpp.

~QCPLayoutElement ( )

virtual

Definition at line 1735 of file qcustomplot.cpp.

References mParentLayout, QCP::msAll, setMarginGroup(), and QCPLayout::take().

Member Function Documentation

virtual void applyDefaultAntialiasingHint ( QCPPainter * painter ) const

inlineprotectedvirtual

Implements QCPLayerable.

Reimplemented in QCPColorScale, QCPPlotTitle, QCPLegend, QCPAbstractLegendItem, and QCPAxisRect.

Definition at line 706 of file qcustomplot.h.

QCP::MarginSides autoMargins ( ) const

inline

Definition at line 661 of file qcustomplot.h.

int calculateAutoMargin ( QCP::MarginSide side )

protectedvirtual

Reimplemented in QCPAxisRect.

Definition at line 2036 of file qcustomplot.cpp.

References QCP::getMarginValue(), mMargins, and mMinimumMargins.

Referenced by update().

virtual void draw ( QCPPainter * painter )

inlineprotectedvirtual

Implements QCPLayerable.

Reimplemented in QCPColorScaleAxisRectPrivate, QCPPlotTitle, QCPLegend, QCPPlottableLegendItem, QCPAbstractLegendItem, and QCPAxisRect.

Definition at line 707 of file qcustomplot.h.

QList< QCPLayoutElement * > elements ( bool recursive ) const

virtual

Returns a list of all child elements in this layout element. If recursive is true, all sub-child elements are included in the list, too.

Warning: There may be entries with value 0 in the returned list. (For example, QCPLayoutGrid may have empty cells which yield 0 at the respective index.)

Reimplemented in QCPAxisRect, QCPLayoutGrid, and QCPLayout.

Definition at line 1976 of file qcustomplot.cpp.

Referenced by QCustomPlot::axisRects(), QCustomPlot::layoutElementAt(), parentPlotInitialized(), and QCustomPlot::selectedLegends().

QCPLayout * layout ( ) const

inline

Returns the parent layout of this layout element.

Definition at line 656 of file qcustomplot.h.

Referenced by QCPLayoutGrid::addElement(), and QCPLayoutInset::addElement().

QCPMarginGroup* marginGroup ( QCP::MarginSide side ) const

inline

Definition at line 664 of file qcustomplot.h.

Referenced by setMarginGroup().

QHash<QCP::MarginSide, QCPMarginGroup*> marginGroups ( ) const

inline

Definition at line 665 of file qcustomplot.h.

QMargins margins ( ) const

inline

Definition at line 659 of file qcustomplot.h.

Referenced by setMargins(), setMinimumMargins(), and QCPColorScale::update().

QSize maximumSize ( ) const

inline

Definition at line 663 of file qcustomplot.h.

QSize maximumSizeHint ( ) const

virtual

Returns the maximum size this layout element (the inner rect) may be expanded to.

if a maximum size (setMaximumSize) was not set manually, parent layouts consult this function to determine the maximum allowed size of this layout element. (A manual maximum size is considered set if it is smaller than Qt's QWIDGETSIZE_MAX.)

Reimplemented in QCPPlotTitle, and QCPLayoutGrid.

Definition at line 1964 of file qcustomplot.cpp.

References mMaximumSize.

QMargins minimumMargins ( ) const

inline

Definition at line 660 of file qcustomplot.h.

QSize minimumSize ( ) const

inline

Definition at line 662 of file qcustomplot.h.

QSize minimumSizeHint ( ) const

virtual

Returns the minimum size this layout element (the inner rect) may be compressed to.

if a minimum size (setMinimumSize) was not set manually, parent layouts consult this function to determine the minimum allowed size of this layout element. (A manual minimum size is considered set if it is non-zero.)

Reimplemented in QCPPlotTitle, QCPPlottableLegendItem, and QCPLayoutGrid.

Definition at line 1952 of file qcustomplot.cpp.

References mMinimumSize.

void mouseDoubleClickEvent ( QMouseEvent * event )

inlineprotectedvirtual

This event is called, if the mouse is double-clicked inside the outer rect of this layout element.

Definition at line 702 of file qcustomplot.h.

void mouseMoveEvent ( QMouseEvent * event )

inlineprotectedvirtual

This event is called, if the mouse is moved inside the outer rect of this layout element.

Reimplemented in QCPColorScale, and QCPAxisRect.

Definition at line 700 of file qcustomplot.h.

void mousePressEvent ( QMouseEvent * event )

inlineprotectedvirtual

This event is called, if the mouse was pressed while being inside the outer rect of this layout element.

Reimplemented in QCPColorScale, and QCPAxisRect.

Definition at line 699 of file qcustomplot.h.

void mouseReleaseEvent ( QMouseEvent * event )

inlineprotectedvirtual

This event is called, if the mouse was previously pressed inside the outer rect of this layout element and is now released.

Reimplemented in QCPColorScale, and QCPAxisRect.

Definition at line 701 of file qcustomplot.h.

QRect outerRect ( ) const

inline

Definition at line 658 of file qcustomplot.h.

void parentPlotInitialized ( QCustomPlot * parentPlot )

protectedvirtual

Reimplemented from QCPLayerable.

Reimplemented in QCPLegend.

Definition at line 2018 of file qcustomplot.cpp.

References elements(), QCPLayerable::initializeParentPlot(), and QCPLayerable::parentPlot().

QRect rect ( ) const

inline

Returns the inner rect of this layout element. The inner rect is the outer rect (setOuterRect) shrinked by the margins (setMargins, setAutoMargins).

In some cases, the area between outer and inner rect is left blank. In other cases the margin area is used to display peripheral graphics while the main content is in the inner rect. This is where automatic margin calculation becomes interesting because it allows the layout element to adapt the margins to the peripheral graphics it wants to draw. For example, QCPAxisRect draws the axis labels and tick labels in the margin area, thus needs to adjust the margins (if setAutoMargins is enabled) according to the space required by the labels of the axes.

Definition at line 657 of file qcustomplot.h.

Referenced by QCPAxis::calculateMargin(), QCPAxis::draw(), QCPColorScaleAxisRectPrivate::draw(), QCustomPlot::plottableAt(), QCPLayoutInset::setInsetRect(), setOuterRect(), QCPAxisRect::update(), QCPColorScale::update(), QCPColorScaleAxisRectPrivate::updateGradientImage(), and QCPLayoutInset::updateLayout().

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

Layout elements are sensitive to events inside their outer rect. If pos is within the outer rect, this method returns a value corresponding to 0.99 times the parent plot's selection tolerance. However, layout elements are not selectable by default. So if onlySelectable is true, -1.0 is returned.

See QCPLayerable::selectTest for a general explanation of this virtual method.

QCPLayoutElement subclasses may reimplement this method to provide more specific selection test behaviour.

Reimplemented from QCPLayerable.

Reimplemented in QCPPlotTitle, QCPLegend, QCPAbstractLegendItem, and QCPLayoutInset.

Definition at line 1993 of file qcustomplot.cpp.

References mOuterRect, QCPLayerable::mParentPlot, and QCustomPlot::selectionTolerance().

Referenced by QCustomPlot::layoutElementAt().

void setAutoMargins ( QCP::MarginSides sides )

Sets on which sides the margin shall be calculated automatically. If a side is calculated automatically, a minimum margin value may be provided with setMinimumMargins. If a side is set to be controlled manually, the value may be specified with setMargins.

Margin sides that are under automatic control may participate in a QCPMarginGroup (see setMarginGroup), to synchronize (align) it with other layout elements in the plot.

See Also: setMinimumMargins, setMargins

Definition at line 1810 of file qcustomplot.cpp.

References mAutoMargins.

void setMarginGroup	(	QCP::MarginSides	sides,
		QCPMarginGroup *	group
	)

Sets the margin group of the specified margin sides.

Margin groups allow synchronizing specified margins across layout elements, see the documentation of QCPMarginGroup.

To unset the margin group of sides, set group to 0.

Note that margin groups only work for margin sides that are set to automatic (setAutoMargins).

Definition at line 1877 of file qcustomplot.cpp.

References QCPMarginGroup::addChild(), marginGroup(), mMarginGroups, QCP::msBottom, QCP::msLeft, QCP::msRight, QCP::msTop, and QCPMarginGroup::removeChild().

Referenced by ~QCPLayoutElement().

void setMargins ( const QMargins & margins )

Sets the margins of this layout element. If setAutoMargins is disabled for some or all sides, this function is used to manually set the margin on those sides. Sides that are still set to be handled automatically are ignored and may have any value in margins.

The margin is the distance between the outer rect (controlled by the parent layout via setOuterRect) and the inner rect (which usually contains the main content of this layout element).

See Also: setAutoMargins

Definition at line 1774 of file qcustomplot.cpp.

References margins(), mMargins, mOuterRect, and mRect.

Referenced by QCPAbstractLegendItem::QCPAbstractLegendItem(), QCPLegend::QCPLegend(), QCPPlotTitle::QCPPlotTitle(), QCustomPlot::QCustomPlot(), and update().

void setMaximumSize ( const QSize & size )

Sets the maximum size for the inner rect of this layout element. A parent layout tries to respect the size here by changing row/column sizes in the layout accordingly.

Definition at line 1847 of file qcustomplot.cpp.

References mMaximumSize, mParentLayout, and QCPLayout::sizeConstraintsChanged().

Referenced by setMaximumSize(), and QCPColorScale::update().

void setMaximumSize	(	int	width,
		int	height
	)

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

Sets the maximum size for the inner rect of this layout element.

Definition at line 1861 of file qcustomplot.cpp.

References setMaximumSize().

void setMinimumMargins ( const QMargins & margins )

If setAutoMargins is enabled on some or all margins, this function is used to provide minimum values for those margins.

The minimum values are not enforced on margin sides that were set to be under manual control via setAutoMargins.

See Also: setAutoMargins

Definition at line 1792 of file qcustomplot.cpp.

References margins(), and mMinimumMargins.

Referenced by QCPAxisRect::QCPAxisRect(), QCPColorScale::QCPColorScale(), and QCPColorScaleAxisRectPrivate::QCPColorScaleAxisRectPrivate().

void setMinimumSize ( const QSize & size )

Sets the minimum size for the inner rect of this layout element. A parent layout tries to respect the size here by changing row/column sizes in the layout accordingly.

If the parent layout size is not sufficient to satisfy all minimum size constraints of its child layout elements, the layout may set a size that is actually smaller than size. QCustomPlot propagates the layout's size constraints to the outside by setting its own minimum QWidget size accordingly, so violations of size should be exceptions.

Definition at line 1824 of file qcustomplot.cpp.

References mMinimumSize, mParentLayout, and QCPLayout::sizeConstraintsChanged().

Referenced by QCPAxisRect::QCPAxisRect(), setMinimumSize(), and QCPColorScale::update().

void setMinimumSize	(	int	width,
		int	height
	)

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

Sets the minimum size for the inner rect of this layout element.

Definition at line 1838 of file qcustomplot.cpp.

References setMinimumSize().

void setOuterRect ( const QRect & rect )

Sets the outer rect of this layout element. If the layout element is inside a layout, the layout sets the position and size of this layout element using this function.

Calling this function externally has no effect, since the layout will overwrite any changes to the outer rect upon the next replot.

The layout element will adapt its inner rect by applying the margins inward to the outer rect.

See Also: rect

Definition at line 1754 of file qcustomplot.cpp.

References mMargins, mOuterRect, mRect, and rect().

Referenced by QCustomPlot::setViewport(), and QCPAxisRect::update().

void update ( UpdatePhase phase )

virtual

Updates the layout element and sub-elements. This function is automatically called before every replot by the parent layout element. It is called multiple times, once for every UpdatePhase. The phases are run through in the order of the enum values. For details about what happens at the different phases, see the documentation of UpdatePhase.

Layout elements that have child elements should call the update method of their child elements, and pass the current phase unchanged.

The default implementation executes the automatic margin mechanism in the upMargins phase. Subclasses should make sure to call the base class implementation.

Reimplemented in QCPColorScale, QCPAxisRect, and QCPLayout.

Definition at line 1918 of file qcustomplot.cpp.

References calculateAutoMargin(), QCP::getMarginValue(), mAutoMargins, mMarginGroups, mMargins, mMinimumMargins, QCP::msBottom, QCP::msLeft, QCP::msNone, QCP::msRight, QCP::msTop, setMargins(), QCP::setMarginValue(), and upMargins.
