#include <qcustomplot.h>

Inheritance diagram for QCPMarginGroup:

Collaboration diagram for QCPMarginGroup:

Public Member Functions
	QCPMarginGroup (QCustomPlot *parentPlot)

	~QCPMarginGroup ()

QList< QCPLayoutElement * >	elements (QCP::MarginSide side) const

bool	isEmpty () const

void	clear ()

Protected Member Functions
int	commonMargin (QCP::MarginSide side) const

void	addChild (QCP::MarginSide side, QCPLayoutElement *element)

void	removeChild (QCP::MarginSide side, QCPLayoutElement *element)

Protected Attributes
QCustomPlot *	mParentPlot

QHash< QCP::MarginSide, QList < QCPLayoutElement * > >	mChildren

Friends
class	QCPLayoutElement

Detailed Description

A margin group allows synchronization of margin sides if working with multiple layout elements.

QCPMarginGroup allows you to tie a margin side of two or more layout elements together, such that they will all have the same size, based on the largest required margin in the group.

Demonstration of QCPMarginGroup

In certain situations it is desirable that margins at specific sides are synchronized across layout elements. For example, if one QCPAxisRect is below another one in a grid layout, it will provide a cleaner look to the user if the left and right margins of the two axis rects are of the same size. The left axis of the top axis rect will then be at the same horizontal position as the left axis of the lower axis rect, making them appear aligned. The same applies for the right axes. This is what QCPMarginGroup makes possible.

To add/remove a specific side of a layout element to/from a margin group, use the QCPLayoutElement::setMarginGroup method. To completely break apart the margin group, either call clear, or just delete the margin group.

Example

First create a margin group:

Then set this group on the layout element sides:

Here, we've used the first two axis rects of the plot and synchronized their left margins with each other and their right margins with each other.

Definition at line 600 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPMarginGroup ( QCustomPlot * parentPlot )

Creates a new QCPMarginGroup instance in parentPlot.

Definition at line 1537 of file qcustomplot.cpp.

References mChildren, QCP::msBottom, QCP::msLeft, QCP::msRight, and QCP::msTop.

~QCPMarginGroup ( )

Definition at line 1547 of file qcustomplot.cpp.

References clear().

Member Function Documentation

void addChild	(	QCP::MarginSide	side,
		QCPLayoutElement *	element
	)

protected

Definition at line 1617 of file qcustomplot.cpp.

References mChildren.

Referenced by QCPLayoutElement::setMarginGroup().

void clear ( )

Clears this margin group. The synchronization of the margin sides that use this margin group is lifted and they will use their individual margin sizes again.

Definition at line 1572 of file qcustomplot.cpp.

References elements(), and mChildren.

Referenced by ~QCPMarginGroup().

int commonMargin ( QCP::MarginSide side ) const

protected

Definition at line 1595 of file qcustomplot.cpp.

References elements(), QCP::getMarginValue(), and mChildren.

QList< QCPLayoutElement * > elements ( QCP::MarginSide side ) const

inline

Returns a list of all layout elements that have their margin side associated with this margin group.

Definition at line 608 of file qcustomplot.h.

Referenced by clear(), and commonMargin().
