#include <qcustomplot.h>

Inheritance diagram for QCPAbstractLegendItem:

Collaboration diagram for QCPAbstractLegendItem:

Signals
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Public Member Functions
	QCPAbstractLegendItem (QCPLegend *parent)

QCPLegend *	parentLegend () const

QFont	font () const

QColor	textColor () const

QFont	selectedFont () const

QColor	selectedTextColor () const

bool	selectable () const

bool	selected () const

void	setFont (const QFont &font)

void	setTextColor (const QColor &color)

void	setSelectedFont (const QFont &font)

void	setSelectedTextColor (const QColor &color)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPLayoutElement
	QCPLayoutElement (QCustomPlot *parentPlot=0)

virtual	~QCPLayoutElement ()

QCPLayout *	layout () const

QRect	rect () const

QRect	outerRect () const

QMargins	margins () const

QMargins	minimumMargins () const

QCP::MarginSides	autoMargins () const

QSize	minimumSize () const

QSize	maximumSize () const

QCPMarginGroup *	marginGroup (QCP::MarginSide side) const

QHash< QCP::MarginSide, QCPMarginGroup * >	marginGroups () const

void	setOuterRect (const QRect &rect)

void	setMargins (const QMargins &margins)

void	setMinimumMargins (const QMargins &margins)

void	setAutoMargins (QCP::MarginSides sides)

void	setMinimumSize (const QSize &size)

void	setMinimumSize (int width, int height)

void	setMaximumSize (const QSize &size)

void	setMaximumSize (int width, int height)

void	setMarginGroup (QCP::MarginSides sides, QCPMarginGroup *group)

virtual void	update (UpdatePhase phase)

virtual QSize	minimumSizeHint () const

virtual QSize	maximumSizeHint () const

virtual QList< QCPLayoutElement * >	elements (bool recursive) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Protected Member Functions
virtual QCP::Interaction	selectionCategory () const

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual QRect	clipRect () const

virtual void	draw (QCPPainter *painter)=0

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

Protected Member Functions inherited from QCPLayoutElement
virtual int	calculateAutoMargin (QCP::MarginSide side)

virtual void	mousePressEvent (QMouseEvent *event)

virtual void	mouseMoveEvent (QMouseEvent *event)

virtual void	mouseReleaseEvent (QMouseEvent *event)

virtual void	mouseDoubleClickEvent (QMouseEvent *event)

virtual void	wheelEvent (QWheelEvent *event)

virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

Protected Member Functions inherited from QCPLayerable
void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QCPLegend *	mParentLegend

QFont	mFont

QColor	mTextColor

QFont	mSelectedFont

QColor	mSelectedTextColor

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayoutElement
QCPLayout *	mParentLayout

QSize	mMinimumSize

QSize	mMaximumSize

QRect	mRect

QRect	mOuterRect

QMargins	mMargins

QMargins	mMinimumMargins

QCP::MarginSides	mAutoMargins

QHash< QCP::MarginSide, QCPMarginGroup * >	mMarginGroups

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Friends
class	QCPLegend

Additional Inherited Members
Public Types inherited from QCPLayoutElement
enum	UpdatePhase { upPreparation, upMargins, upLayout }

Detailed Description

The abstract base class for all entries in a QCPLegend.

It defines a very basic interface for entries in a QCPLegend. For representing plottables in the legend, the subclass QCPPlottableLegendItem is more suitable.

Only derive directly from this class when you need absolute freedom (e.g. a custom legend entry that's not even associated with a plottable).

You must implement the following pure virtual functions:

draw (from QCPLayerable)

You inherit the following members you may use:

QCPLegend *mParentLegend	A pointer to the parent QCPLegend.
QFont mFont	The generic font of the item. You should use this font for all or at least the most prominent text of the item.

Definition at line 2081 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPAbstractLegendItem ( QCPLegend * parent )

explicit

Constructs a QCPAbstractLegendItem and associates it with the QCPLegend parent. This does not cause the item to be added to parent, so QCPLegend::addItem must be called separately.

Definition at line 12647 of file qcustomplot.cpp.

References QCPLayerable::setLayer(), and QCPLayoutElement::setMargins().

Member Function Documentation

void applyDefaultAntialiasingHint ( QCPPainter * painter ) const

protectedvirtual

Reimplemented from QCPLayoutElement.

Definition at line 12749 of file qcustomplot.cpp.

References QCP::aeLegendItems, QCPLayerable::applyAntialiasingHint(), and QCPLayerable::mAntialiased.

QRect clipRect ( ) const

protectedvirtual

Reimplemented from QCPLayerable.

Definition at line 12755 of file qcustomplot.cpp.

References QCPLayoutElement::mOuterRect.

void deselectEvent ( bool * selectionStateChanged )

protectedvirtual

Reimplemented from QCPLayerable.

Definition at line 12775 of file qcustomplot.cpp.

References mParentLegend, mSelectable, mSelected, QCPLegend::selectableParts(), setSelected(), and QCPLegend::spItems.

virtual void draw ( QCPPainter * painter )

protectedpure virtual

Reimplemented from QCPLayoutElement.

Implemented in QCPPlottableLegendItem.

QFont font ( ) const

inline

Definition at line 2098 of file qcustomplot.h.

Referenced by setFont(), and setSelectedFont().

QCPLegend* parentLegend ( ) const

inline

Definition at line 2097 of file qcustomplot.h.

bool selectable ( ) const

inline

Definition at line 2102 of file qcustomplot.h.

Referenced by setSelectable().

void selectableChanged ( bool selectable )

signal

Referenced by setSelectable().

bool selected ( ) const

inline

Definition at line 2103 of file qcustomplot.h.

Referenced by QCPLegend::selectedParts(), and setSelected().

QFont selectedFont ( ) const

inline

Definition at line 2100 of file qcustomplot.h.

QColor selectedTextColor ( ) const

inline

Definition at line 2101 of file qcustomplot.h.

void selectEvent	(	QMouseEvent *	event,
		bool	additive,
		const QVariant &	details,
		bool *	selectionStateChanged
	)

protectedvirtual

Reimplemented from QCPLayerable.

Definition at line 12761 of file qcustomplot.cpp.

References mParentLegend, mSelectable, mSelected, QCPLegend::selectableParts(), setSelected(), and QCPLegend::spItems.

QCP::Interaction selectionCategory ( ) const

protectedvirtual

Reimplemented from QCPLayerable.

Definition at line 13465 of file qcustomplot.cpp.

References QCP::iSelectLegend.

void selectionChanged ( bool selected )

signal

This signal is emitted when the selection state of this legend item has changed, either by user interaction or by a direct call to setSelected.

Referenced by setSelected().

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

Layout elements are sensitive to events inside their outer rect. If pos is within the outer rect, this method returns a value corresponding to 0.99 times the parent plot's selection tolerance. However, layout elements are not selectable by default. So if onlySelectable is true, -1.0 is returned.

See QCPLayerable::selectTest for a general explanation of this virtual method.

QCPLayoutElement subclasses may reimplement this method to provide more specific selection test behaviour.

Reimplemented from QCPLayoutElement.

Definition at line 12735 of file qcustomplot.cpp.

References mParentLegend, QCPLayerable::mParentPlot, QCPLayoutElement::mRect, mSelectable, QCPLegend::selectableParts(), QCustomPlot::selectionTolerance(), and QCPLegend::spItems.

void setFont ( const QFont & font )

Sets the default font of this specific legend item to font.
