#include <qcustomplot.h>

Inheritance diagram for QCPPlotTitle:

Collaboration diagram for QCPPlotTitle:

Signals
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Public Member Functions
	QCPPlotTitle (QCustomPlot *parentPlot)

	QCPPlotTitle (QCustomPlot *parentPlot, const QString &text)

QString	text () const

QFont	font () const

QColor	textColor () const

QFont	selectedFont () const

QColor	selectedTextColor () const

bool	selectable () const

bool	selected () const

void	setText (const QString &text)

void	setFont (const QFont &font)

void	setTextColor (const QColor &color)

void	setSelectedFont (const QFont &font)

void	setSelectedTextColor (const QColor &color)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPLayoutElement
	QCPLayoutElement (QCustomPlot *parentPlot=0)

virtual	~QCPLayoutElement ()

QCPLayout *	layout () const

QRect	rect () const

QRect	outerRect () const

QMargins	margins () const

QMargins	minimumMargins () const

QCP::MarginSides	autoMargins () const

QSize	minimumSize () const

QSize	maximumSize () const

QCPMarginGroup *	marginGroup (QCP::MarginSide side) const

QHash< QCP::MarginSide, QCPMarginGroup * >	marginGroups () const

void	setOuterRect (const QRect &rect)

void	setMargins (const QMargins &margins)

void	setMinimumMargins (const QMargins &margins)

void	setAutoMargins (QCP::MarginSides sides)

void	setMinimumSize (const QSize &size)

void	setMinimumSize (int width, int height)

void	setMaximumSize (const QSize &size)

void	setMaximumSize (int width, int height)

void	setMarginGroup (QCP::MarginSides sides, QCPMarginGroup *group)

virtual void	update (UpdatePhase phase)

virtual QList< QCPLayoutElement * >	elements (bool recursive) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Protected Member Functions
virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	draw (QCPPainter *painter)

virtual QSize	minimumSizeHint () const

virtual QSize	maximumSizeHint () const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

QFont	mainFont () const

QColor	mainTextColor () const

Protected Member Functions inherited from QCPLayoutElement
virtual int	calculateAutoMargin (QCP::MarginSide side)

virtual void	mousePressEvent (QMouseEvent *event)

virtual void	mouseMoveEvent (QMouseEvent *event)

virtual void	mouseReleaseEvent (QMouseEvent *event)

virtual void	mouseDoubleClickEvent (QMouseEvent *event)

virtual void	wheelEvent (QWheelEvent *event)

virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

Protected Member Functions inherited from QCPLayerable
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QString	mText

QFont	mFont

QColor	mTextColor

QFont	mSelectedFont

QColor	mSelectedTextColor

QRect	mTextBoundingRect

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayoutElement
QCPLayout *	mParentLayout

QSize	mMinimumSize

QSize	mMaximumSize

QRect	mRect

QRect	mOuterRect

QMargins	mMargins

QMargins	mMinimumMargins

QCP::MarginSides	mAutoMargins

QHash< QCP::MarginSide, QCPMarginGroup * >	mMarginGroups

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Additional Inherited Members
Public Types inherited from QCPLayoutElement
enum	UpdatePhase { upPreparation, upMargins, upLayout }

Detailed Description

A layout element displaying a plot title text.

The text may be specified with setText, theformatting can be controlled with setFont and setTextColor.

A plot title can be added as follows:

Since a plot title is a common requirement, QCustomPlot offers specialized selection signals for easy interaction with QCPPlotTitle. If a layout element of type QCPPlotTitle is clicked, the signal QCustomPlot::titleClick is emitted. A double click emits the QCustomPlot::titleDoubleClick signal.

Definition at line 2293 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPPlotTitle ( QCustomPlot * parentPlot )

explicit

Creates a new QCPPlotTitle instance and sets default values. The initial text is empty (setText).

To set the title text in the constructor, rather use QCPPlotTitle(QCustomPlot *parentPlot, const QString &text).

Definition at line 13513 of file qcustomplot.cpp.

References QCustomPlot::currentLayer(), mFont, mSelectedFont, QCPLayerable::setLayer(), and QCPLayoutElement::setMargins().

QCPPlotTitle	(	QCustomPlot *	parentPlot,
		const QString &	text
	)

explicit

This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts.

Creates a new QCPPlotTitle instance and sets default values. The initial text is set to text.

Definition at line 13535 of file qcustomplot.cpp.

References QCPLayerable::setLayer(), and QCPLayoutElement::setMargins().

Member Function Documentation

void applyDefaultAntialiasingHint ( QCPPainter * painter ) const

protectedvirtual

Reimplemented from QCPLayoutElement.

Definition at line 13631 of file qcustomplot.cpp.

References QCP::aeNone, QCPLayerable::applyAntialiasingHint(), and QCPLayerable::mAntialiased.

void deselectEvent ( bool * selectionStateChanged )

protectedvirtual

Reimplemented from QCPLayerable.

Definition at line 13679 of file qcustomplot.cpp.

References mSelectable, mSelected, and setSelected().

void draw ( QCPPainter * painter )

protectedvirtual

Reimplemented from QCPLayoutElement.

Definition at line 13637 of file qcustomplot.cpp.

References mainFont(), mainTextColor(), QCPLayoutElement::mRect, mText, mTextBoundingRect, and QCPPainter::setPen().

QFont font ( ) const

inline

Definition at line 2311 of file qcustomplot.h.

Referenced by setFont(), and setSelectedFont().

QFont mainFont ( ) const

protected

Definition at line 13708 of file qcustomplot.cpp.

References mFont, mSelected, and mSelectedFont.

Referenced by draw().

QColor mainTextColor ( ) const

protected

Definition at line 13718 of file qcustomplot.cpp.

References mSelected, mSelectedTextColor, and mTextColor.

Referenced by draw().

QSize maximumSizeHint ( ) const

protectedvirtual

Returns the maximum size this layout element (the inner rect) may be expanded to.

if a maximum size (setMaximumSize) was not set manually, parent layouts consult this function to determine the maximum allowed size of this layout element. (A manual maximum size is considered set if it is smaller than Qt's QWIDGETSIZE_MAX.)

Reimplemented from QCPLayoutElement.

Definition at line 13655 of file qcustomplot.cpp.

References mFont, QCPLayoutElement::mMargins, and mText.

QSize minimumSizeHint ( ) const

protectedvirtual

Returns the minimum size this layout element (the inner rect) may be compressed to.

if a minimum size (setMinimumSize) was not set manually, parent layouts consult this function to determine the minimum allowed size of this layout element. (A manual minimum size is considered set if it is non-zero.)

Reimplemented from QCPLayoutElement.

Definition at line 13645 of file qcustomplot.cpp.

References mFont, QCPLayoutElement::mMargins, and mText.

bool selectable ( ) const

inline

Definition at line 2315 of file qcustomplot.h.

Referenced by setSelectable().

void selectableChanged ( bool selectable )

signal

Referenced by setSelectable().

bool selected ( ) const

inline

Definition at line 2316 of file qcustomplot.h.

Referenced by setSelected().

QFont selectedFont ( ) const

inline

Definition at line 2313 of file qcustomplot.h.

QColor selectedTextColor ( ) const

inline

Definition at line 2314 of file qcustomplot.h.

void selectEvent	(	QMouseEvent *	event,
		bool	additive,
		const QVariant &	details,
		bool *	selectionStateChanged
	)

protectedvirtual

Reimplemented from QCPLayerable.

Definition at line 13665 of file qcustomplot.cpp.

References mSelectable, mSelected, and setSelected().

void selectionChanged ( bool selected )

signal

This signal is emitted when the selection state has changed to selected, either by user interaction or by a direct call to setSelected.

See Also: setSelected, setSelectable

Referenced by setSelected().

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

Layout elements are sensitive to events inside their outer rect. If pos is within the outer rect, this method returns a value corresponding to 0.99 times the parent plot's selection tolerance. However, layout elements are not selectable by default. So if onlySelectable is true, -1.0 is returned.

See QCPLayerable::selectTest for a general explanation of this virtual method.

QCPLayoutElement subclasses may reimplement this method to provide more specific selection test behaviour.

Reimplemented from QCPLayoutElement.

Definition at line 13691 of file qcustomplot.cpp.

References QCPLayerable::mParentPlot, mSelectable, mTextBoundingRect, and QCustomPlot::selectionTolerance().

void setFont ( const QFont & font )

Sets the font of the title text.
