#include <qcustomplot.h>

Inheritance diagram for QCPLayoutInset:

Collaboration diagram for QCPLayoutInset:

Public Types
enum	InsetPlacement { ipFree, ipBorderAligned }

Public Types inherited from QCPLayoutElement
enum	UpdatePhase { upPreparation, upMargins, upLayout }

Public Member Functions
	QCPLayoutInset ()

virtual	~QCPLayoutInset ()

InsetPlacement	insetPlacement (int index) const

Qt::Alignment	insetAlignment (int index) const

QRectF	insetRect (int index) const

void	setInsetPlacement (int index, InsetPlacement placement)

void	setInsetAlignment (int index, Qt::Alignment alignment)

void	setInsetRect (int index, const QRectF &rect)

virtual void	updateLayout ()

virtual int	elementCount () const

virtual QCPLayoutElement *	elementAt (int index) const

virtual QCPLayoutElement *	takeAt (int index)

virtual bool	take (QCPLayoutElement *element)

virtual void	simplify ()

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

void	addElement (QCPLayoutElement *element, Qt::Alignment alignment)

void	addElement (QCPLayoutElement *element, const QRectF &rect)

Public Member Functions inherited from QCPLayout
	QCPLayout ()

virtual void	update (UpdatePhase phase)

virtual QList< QCPLayoutElement * >	elements (bool recursive) const

bool	removeAt (int index)

bool	remove (QCPLayoutElement *element)

void	clear ()

Public Member Functions inherited from QCPLayoutElement
	QCPLayoutElement (QCustomPlot *parentPlot=0)

virtual	~QCPLayoutElement ()

QCPLayout *	layout () const

QRect	rect () const

QRect	outerRect () const

QMargins	margins () const

QMargins	minimumMargins () const

QCP::MarginSides	autoMargins () const

QSize	minimumSize () const

QSize	maximumSize () const

QCPMarginGroup *	marginGroup (QCP::MarginSide side) const

QHash< QCP::MarginSide, QCPMarginGroup * >	marginGroups () const

void	setOuterRect (const QRect &rect)

void	setMargins (const QMargins &margins)

void	setMinimumMargins (const QMargins &margins)

void	setAutoMargins (QCP::MarginSides sides)

void	setMinimumSize (const QSize &size)

void	setMinimumSize (int width, int height)

void	setMaximumSize (const QSize &size)

void	setMaximumSize (int width, int height)

void	setMarginGroup (QCP::MarginSides sides, QCPMarginGroup *group)

virtual QSize	minimumSizeHint () const

virtual QSize	maximumSizeHint () const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Protected Attributes
QList< QCPLayoutElement * >	mElements

QList< InsetPlacement >	mInsetPlacement

QList< Qt::Alignment >	mInsetAlignment

QList< QRectF >	mInsetRect

Protected Attributes inherited from QCPLayoutElement
QCPLayout *	mParentLayout

QSize	mMinimumSize

QSize	mMaximumSize

QRect	mRect

QRect	mOuterRect

QMargins	mMargins

QMargins	mMinimumMargins

QCP::MarginSides	mAutoMargins

QHash< QCP::MarginSide, QCPMarginGroup * >	mMarginGroups

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Additional Inherited Members
Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Protected Member Functions inherited from QCPLayout
void	sizeConstraintsChanged () const

void	adoptElement (QCPLayoutElement *el)

void	releaseElement (QCPLayoutElement *el)

QVector< int >	getSectionSizes (QVector< int > maxSizes, QVector< int > minSizes, QVector< double > stretchFactors, int totalSize) const

Protected Member Functions inherited from QCPLayoutElement
virtual int	calculateAutoMargin (QCP::MarginSide side)

virtual void	mousePressEvent (QMouseEvent *event)

virtual void	mouseMoveEvent (QMouseEvent *event)

virtual void	mouseReleaseEvent (QMouseEvent *event)

virtual void	mouseDoubleClickEvent (QMouseEvent *event)

virtual void	wheelEvent (QWheelEvent *event)

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	draw (QCPPainter *painter)

virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

Protected Member Functions inherited from QCPLayerable
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Detailed Description

A layout that places child elements aligned to the border or arbitrarily positioned.

Elements are placed either aligned to the border or at arbitrary position in the area of the layout. Which placement applies is controlled with the InsetPlacement (setInsetPlacement).

Elements are added via addElement(QCPLayoutElement *element, Qt::Alignment alignment) or addElement(QCPLayoutElement *element, const QRectF &rect). If the first method is used, the inset placement will default to ipBorderAligned and the element will be aligned according to the alignment parameter. The second method defaults to ipFree and allows placing elements at arbitrary position and size, defined by rect.

The alignment or rect can be set via setInsetAlignment or setInsetRect, respectively.

This is the layout that every QCPAxisRect has as QCPAxisRect::insetLayout.

Definition at line 823 of file qcustomplot.h.

Member Enumeration Documentation

enum InsetPlacement

Defines how the placement and sizing is handled for a certain element in a QCPLayoutInset.

Enumerator
ipFree	The element may be positioned/sized arbitrarily, see setInsetRect.
ipBorderAligned	The element is aligned to one of the layout sides, see setInsetAlignment.

Definition at line 830 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPLayoutInset ( )

explicit

Creates an instance of QCPLayoutInset and sets default values.

Definition at line 3079 of file qcustomplot.cpp.

~QCPLayoutInset ( )

virtual

Definition at line 3083 of file qcustomplot.cpp.

References QCPLayout::clear().

Member Function Documentation

void addElement	(	QCPLayoutElement *	element,
		Qt::Alignment	alignment
	)

Adds the specified element to the layout as an inset aligned at the border (setInsetAlignment is initialized with ipBorderAligned). The alignment is set to alignment.

alignment is an or combination of the following alignment flags: Qt::AlignLeft, Qt::AlignHCenter, Qt::AlighRight, Qt::AlignTop, Qt::AlignVCenter, Qt::AlignBottom. Any other alignment flags will be ignored.

See Also: addElement(QCPLayoutElement *element, const QRectF &rect)

Definition at line 3312 of file qcustomplot.cpp.

References QCPLayout::adoptElement(), ipBorderAligned, QCPLayoutElement::layout(), mElements, mInsetAlignment, mInsetPlacement, mInsetRect, and QCPLayout::take().

Referenced by QCustomPlot::QCustomPlot().

void addElement	(	QCPLayoutElement *	element,
		const QRectF &	rect
	)

Adds the specified element to the layout as an inset with free positioning/sizing (setInsetAlignment is initialized with ipFree). The position and size is set to rect.

rect is given in fractions of the whole inset layout rect. So an inset with rect (0, 0, 1, 1) will span the entire layout. An inset with rect (0.6, 0.1, 0.35, 0.35) will be in the top right corner of the layout, with 35% width and height of the parent layout.

See Also: addElement(QCPLayoutElement *element, Qt::Alignment alignment)

Definition at line 3338 of file qcustomplot.cpp.

References QCPLayout::adoptElement(), ipFree, QCPLayoutElement::layout(), mElements, mInsetAlignment, mInsetPlacement, mInsetRect, and QCPLayout::take().

QCPLayoutElement * elementAt ( int index ) const

virtual

Returns the element in the cell with the given index. If index is invalid, returns 0.

Note that even if index is valid, the respective cell may be empty in some layouts (e.g. QCPLayoutGrid), so this function may return 0 in those cases. You may use this function to check whether a cell is empty or not.

See Also: elements, elementCount, takeAt

Implements QCPLayout.

Definition at line 3231 of file qcustomplot.cpp.

References mElements.

Referenced by insetAlignment(), insetPlacement(), insetRect(), setInsetAlignment(), setInsetPlacement(), setInsetRect(), take(), and takeAt().

int elementCount ( ) const

virtual

Returns the number of elements/cells in the layout.

See Also: elements, elementAt

Implements QCPLayout.

Definition at line 3225 of file qcustomplot.cpp.

References mElements.

Referenced by take().

Qt::Alignment insetAlignment ( int index ) const

Returns the alignment of the element with the specified index. The alignment only has a meaning, if the inset placement (setInsetPlacement) is ipBorderAligned.

Definition at line 3108 of file qcustomplot.cpp.

References elementAt(), and mInsetAlignment.

QCPLayoutInset::InsetPlacement insetPlacement ( int index ) const

Returns the placement type of the element with the specified index.

Definition at line 3093 of file qcustomplot.cpp.

References elementAt(), ipFree, and mInsetPlacement.

QRectF insetRect ( int index ) const

Returns the rect of the element with the specified index. The rect only has a meaning, if the inset placement (setInsetPlacement) is ipFree.

Definition at line 3123 of file qcustomplot.cpp.

References elementAt(), and mInsetRect.

Referenced by updateLayout().

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

The inset layout is sensitive to events only at areas where its (visible) child elements are sensitive. If the selectTest method of any of the child elements returns a positive number for pos, this method returns a value corresponding to 0.99 times the parent plot's selection tolerance. The inset layout is not selectable itself by default. So if onlySelectable is true, -1.0 is returned.

See QCPLayerable::selectTest for a general explanation of this virtual method.

Reimplemented from QCPLayoutElement.

Definition at line 3285 of file qcustomplot.cpp.

References mElements, QCPLayerable::mParentPlot, and QCustomPlot::selectionTolerance().

void setInsetAlignment	(	int	index,
		Qt::Alignment	alignment
	)

If the inset placement (setInsetPlacement) is ipBorderAligned, this function is used to set the alignment of the element with the specified index to alignment.

alignment is an or combination of the following alignment flags: Qt::AlignLeft, Qt::AlignHCenter, Qt::AlighRight, Qt::AlignTop, Qt::AlignVCenter, Qt::AlignBottom. Any other alignment flags will be ignored.

Definition at line 3155 of file qcustomplot.cpp.

References elementAt(), and mInsetAlignment.

void setInsetPlacement	(	int	index,
		QCPLayoutInset::InsetPlacement	placement
	)

Sets the inset placement type of the element with the specified index to placement.

See Also: InsetPlacement

Definition at line 3139 of file qcustomplot.cpp.

References elementAt(), and mInsetPlacement.

void setInsetRect	(	int	index,
		const QRectF &	rect
	)

If the inset placement (setInsetPlacement) is ipFree, this function is used to set the position and size of the element with the specified index to rect.

rect is given in fractions of the whole inset layout rect. So an inset with rect (0, 0, 1, 1) will span the entire layout. An inset with rect (0.6, 0.1, 0.35, 0.35) will be in the top right corner of the layout, with 35% width and height of the parent layout.

Note that the minimum and maximum sizes of the embedded element (QCPLayoutElement::setMinimumSize, QCPLayoutElement::setMaximumSize) are enforced.

Definition at line 3174 of file qcustomplot.cpp.

References elementAt(), mInsetRect, and QCPLayoutElement::rect().

void simplify ( )

inlinevirtual

The QCPInsetLayout does not need simplification since it can never have empty cells due to its linear index structure. This method does nothing.

Reimplemented from QCPLayout.

Definition at line 853 of file qcustomplot.h.

bool take ( QCPLayoutElement * element )

virtual

Removes the specified element from the layout and returns true on success.

If the element isn't in this layout, returns false.

Note that some layouts don't remove the respective cell right away but leave an empty cell after successful removal of the layout element. To collapse empty cells, use simplify.

See Also: takeAt

Implements QCPLayout.

Definition at line 3258 of file qcustomplot.cpp.

References elementAt(), elementCount(), and takeAt().

QCPLayoutElement * takeAt ( int index )

virtual

Removes the element with the given index from the layout and returns it.

If the index is invalid or the cell with that index is empty, returns 0.

Note that some layouts don't remove the respective cell right away but leave an empty cell after successful removal of the layout element. To collapse empty cells, use simplify.
