#include <qcustomplot.h>

Inheritance diagram for QCPColorScale:

Collaboration diagram for QCPColorScale:

Signals
void	dataRangeChanged (QCPRange newRange)

void	dataScaleTypeChanged (QCPAxis::ScaleType scaleType)

void	gradientChanged (QCPColorGradient newGradient)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Public Member Functions
	QCPColorScale (QCustomPlot *parentPlot)

virtual	~QCPColorScale ()

QCPAxis *	axis () const

QCPAxis::AxisType	type () const

QCPRange	dataRange () const

QCPAxis::ScaleType	dataScaleType () const

QCPColorGradient	gradient () const

QString	label () const

int	barWidth () const

bool	rangeDrag () const

bool	rangeZoom () const

void	setType (QCPAxis::AxisType type)

Q_SLOT void	setDataRange (const QCPRange &dataRange)

Q_SLOT void	setDataScaleType (QCPAxis::ScaleType scaleType)

Q_SLOT void	setGradient (const QCPColorGradient &gradient)

void	setLabel (const QString &str)

void	setBarWidth (int width)

void	setRangeDrag (bool enabled)

void	setRangeZoom (bool enabled)

QList< QCPColorMap * >	colorMaps () const

void	rescaleDataRange (bool onlyVisibleMaps)

virtual void	update (UpdatePhase phase)

Public Member Functions inherited from QCPLayoutElement
	QCPLayoutElement (QCustomPlot *parentPlot=0)

virtual	~QCPLayoutElement ()

QCPLayout *	layout () const

QRect	rect () const

QRect	outerRect () const

QMargins	margins () const

QMargins	minimumMargins () const

QCP::MarginSides	autoMargins () const

QSize	minimumSize () const

QSize	maximumSize () const

QCPMarginGroup *	marginGroup (QCP::MarginSide side) const

QHash< QCP::MarginSide, QCPMarginGroup * >	marginGroups () const

void	setOuterRect (const QRect &rect)

void	setMargins (const QMargins &margins)

void	setMinimumMargins (const QMargins &margins)

void	setAutoMargins (QCP::MarginSides sides)

void	setMinimumSize (const QSize &size)

void	setMinimumSize (int width, int height)

void	setMaximumSize (const QSize &size)

void	setMaximumSize (int width, int height)

void	setMarginGroup (QCP::MarginSides sides, QCPMarginGroup *group)

virtual QSize	minimumSizeHint () const

virtual QSize	maximumSizeHint () const

virtual QList< QCPLayoutElement * >	elements (bool recursive) const

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Protected Member Functions
virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	mousePressEvent (QMouseEvent *event)

virtual void	mouseMoveEvent (QMouseEvent *event)

virtual void	mouseReleaseEvent (QMouseEvent *event)

virtual void	wheelEvent (QWheelEvent *event)

Protected Member Functions inherited from QCPLayoutElement
virtual int	calculateAutoMargin (QCP::MarginSide side)

virtual void	mouseDoubleClickEvent (QMouseEvent *event)

virtual void	draw (QCPPainter *painter)

virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

Protected Member Functions inherited from QCPLayerable
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QCPAxis::AxisType	mType

QCPRange	mDataRange

QCPAxis::ScaleType	mDataScaleType

QCPColorGradient	mGradient

int	mBarWidth

QPointer < QCPColorScaleAxisRectPrivate >	mAxisRect

QPointer< QCPAxis >	mColorAxis

Protected Attributes inherited from QCPLayoutElement
QCPLayout *	mParentLayout

QSize	mMinimumSize

QSize	mMaximumSize

QRect	mRect

QRect	mOuterRect

QMargins	mMargins

QMargins	mMinimumMargins

QCP::MarginSides	mAutoMargins

QHash< QCP::MarginSide, QCPMarginGroup * >	mMarginGroups

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Friends
class	QCPColorScaleAxisRectPrivate

Additional Inherited Members
Public Types inherited from QCPLayoutElement
enum	UpdatePhase { upPreparation, upMargins, upLayout }

Detailed Description

A color scale for use with color coding data such as QCPColorMap.

This layout element can be placed on the plot to correlate a color gradient with data values. It is usually used in combination with one or multiple QCPColorMaps.

The color scale can be either horizontal or vertical, as shown in the image above. The orientation and the side where the numbers appear is controlled with setType.

Use QCPColorMap::setColorScale to connect a color map with a color scale. Once they are connected, they share their gradient, data range and data scale type (setGradient, setDataRange, setDataScaleType). Multiple color maps may be associated with a single color scale, to make them all synchronize these properties.

To have finer control over the number display and axis behaviour, you can directly access the axis. See the documentation of QCPAxis for details about configuring axes. For example, if you want to change the number of automatically generated ticks, call

Placing a color scale next to the main axis rect works like with any other layout element:

In this case we have placed it to the right of the default axis rect, so it wasn't necessary to call setType, since QCPAxis::atRight is already the default. The text next to the color scale can be set with setLabel.

For optimum appearance (like in the image above), it may be desirable to line up the axis rect and the borders of the color scale. Use a QCPMarginGroup to achieve this:

Color scales are initialized with a non-zero minimum top and bottom margin (setMinimumMargins), because vertical color scales are most common and the minimum top/bottom margin makes sure it keeps some distance to the top/bottom widget border. So if you change to a horizontal color scale by setting setType to QCPAxis::atBottom or QCPAxis::atTop, you might want to also change the minimum margins accordingly, e.g. setMinimumMargins(QMargins(6, 0, 6, 0)).

Definition at line 2386 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPColorScale ( QCustomPlot * parentPlot )

explicit

Constructs a new QCPColorScale.

Definition at line 13810 of file qcustomplot.cpp.

References QCPAxis::atRight, setDataRange(), QCPLayoutElement::setMinimumMargins(), and setType().

~QCPColorScale ( )

virtual

Definition at line 13822 of file qcustomplot.cpp.

References mAxisRect.

Member Function Documentation

void applyDefaultAntialiasingHint ( QCPPainter * painter ) const

protectedvirtual

Reimplemented from QCPLayoutElement.

Definition at line 14158 of file qcustomplot.cpp.

References QCPPainter::setAntialiasing().

QCPAxis * axis ( ) const

inline

Returns the internal QCPAxis instance of this color scale. You can access it to alter the appearance and behaviour of the axis. QCPColorScale duplicates some properties in its interface for convenience. Those are setDataRange (QCPAxis::setRange), setDataScaleType (QCPAxis::setScaleType), and the method setLabel (QCPAxis::setLabel). As they each are connected, it does not matter whether you use the method on the QCPColorScale or on its QCPAxis.

If the type of the color scale is changed with setType, the axis returned by this method will change, too, to either the left, right, bottom or top axis, depending on which type was set.

Definition at line 2404 of file qcustomplot.h.

int barWidth ( ) const

inline

Definition at line 2410 of file qcustomplot.h.

QList< QCPColorMap * > colorMaps ( ) const

Returns a list of all the color maps associated with this color scale.

Definition at line 14044 of file qcustomplot.cpp.

References QCPLayerable::mParentPlot, QCustomPlot::plottable(), and QCustomPlot::plottableCount().

Referenced by rescaleDataRange().

QCPRange dataRange ( ) const

inline

Definition at line 2406 of file qcustomplot.h.

Referenced by setDataRange().

void dataRangeChanged ( QCPRange newRange )

signal

This signal is emitted when the data range changes.

See Also: setDataRange

Referenced by setDataRange().

QCPAxis::ScaleType dataScaleType ( ) const

inline

Definition at line 2407 of file qcustomplot.h.

void dataScaleTypeChanged ( QCPAxis::ScaleType scaleType )

signal

This signal is emitted when the data scale type changes.

See Also: setDataScaleType

Referenced by setDataScaleType().

QCPColorGradient gradient ( ) const

inline

Definition at line 2408 of file qcustomplot.h.

Referenced by setGradient().

void gradientChanged ( QCPColorGradient newGradient )

signal

This signal is emitted when the gradient changes.

See Also: setGradient

Referenced by setGradient().

QString label ( ) const

Definition at line 13828 of file qcustomplot.cpp.

References mColorAxis.

void mouseMoveEvent ( QMouseEvent * event )

protectedvirtual

This event is called, if the mouse is moved inside the outer rect of this layout element.

Reimplemented from QCPLayoutElement.

Definition at line 14175 of file qcustomplot.cpp.

References mAxisRect.

void mousePressEvent ( QMouseEvent * event )

protectedvirtual

This event is called, if the mouse was pressed while being inside the outer rect of this layout element.

Reimplemented from QCPLayoutElement.

Definition at line 14164 of file qcustomplot.cpp.

References mAxisRect.

void mouseReleaseEvent ( QMouseEvent * event )

protectedvirtual

This event is called, if the mouse was previously pressed inside the outer rect of this layout element and is now released.

Reimplemented from QCPLayoutElement.

Definition at line 14186 of file qcustomplot.cpp.

References mAxisRect.

bool rangeDrag ( ) const

Definition at line 13840 of file qcustomplot.cpp.

References mAxisRect, mType, and QCPAxis::orientation().

bool rangeZoom ( ) const

Definition at line 13854 of file qcustomplot.cpp.

References mAxisRect, mType, and QCPAxis::orientation().

void rescaleDataRange ( bool onlyVisibleMaps )

Changes the data range such that all color maps associated with this color scale are fully mapped to the gradient in the data dimension.

See Also: setDataRange

Definition at line 14062 of file qcustomplot.cpp.

References colorMaps(), QCPRange::expand(), QCPRange::lower, mDataRange, mDataScaleType, setDataRange(), QCPRange::size(), QCPAxis::stLinear, QCPAxis::stLogarithmic, QCPRange::upper, and QCPRange::validRange().

void setBarWidth ( int width )

Sets the width (or height, for horizontal color scales) the bar where the gradient is displayed will have.

Definition at line 13996 of file qcustomplot.cpp.

References mBarWidth.

void setDataRange ( const QCPRange & dataRange )

Sets the range spanned by the color gradient and that is shown by the axis in the color scale.

It is equivalent to calling QCPColorMap::setDataRange on any of the connected color maps. It is also equivalent to directly accessing the axis and setting its range with QCPAxis::setRange.

See Also: setDataScaleType, setGradient, rescaleDataRange

Definition at line 13925 of file qcustomplot.cpp.

References dataRange(), dataRangeChanged(), QCPRange::lower, mColorAxis, mDataRange, and QCPRange::upper.

Referenced by QCPColorScale(), rescaleDataRange(), setDataScaleType(), and setType().

void setDataScaleType ( QCPAxis::ScaleType scaleType )

Sets the scale type of the color scale, i.e. whether values are linearly associated with colors or logarithmically.

It is equivalent to calling QCPColorMap::setDataScaleType on any of the connected color maps. It is also equivalent to directly accessing the axis and setting its scale type with QCPAxis::setScaleType.

See Also: setDataRange, setGradient

Definition at line 13946 of file qcustomplot.cpp.

References dataScaleTypeChanged(), mColorAxis, mDataRange, mDataScaleType, QCPRange::sanitizedForLogScale(), setDataRange(), and QCPAxis::stLogarithmic.

Referenced by setType().

void setGradient ( const QCPColorGradient & gradient )

Sets the color gradient that will be used to represent data values.

It is equivalent to calling QCPColorMap::setGradient on any of the connected color maps.

See Also: setDataRange, setDataScaleType

Definition at line 13966 of file qcustomplot.cpp.

References gradient(), gradientChanged(), mAxisRect, and mGradient.

void setLabel ( const QString & str )

Sets the axis label of the color scale. This is equivalent to calling QCPAxis::setLabel on the internal axis.

Definition at line 13981 of file qcustomplot.cpp.

References mColorAxis.

void setRangeDrag ( bool enabled )

Sets whether the user can drag the data range (setDataRange).

Note that QCP::iRangeDrag must be in the QCustomPlot's interactions (QCustomPlot::setInteractions) to allow range dragging.

Definition at line 14007 of file qcustomplot.cpp.

References mAxisRect, mType, and QCPAxis::orientation().

void setRangeZoom ( bool enabled )

Sets whether the user can zoom the data range (setDataRange) by scrolling the mouse wheel.

Note that QCP::iRangeZoom must be in the QCustomPlot's interactions (QCustomPlot::setInteractions) to allow range dragging.

Definition at line 14027 of file qcustomplot.cpp.

References mAxisRect, mType, and QCPAxis::orientation().

void setType ( QCPAxis::AxisType type )

Sets at which side of the color scale the axis is placed, and thus also its orientation.

Note that after setting type to a different value, the axis returned by axis() will be a different one. The new axis will adopt the following properties from the previous axis: The range, scale type, log base and label.

Definition at line 13874 of file qcustomplot.cpp.

References QCPAxis::atBottom, QCPAxis::atLeft, QCPAxis::atRight, QCPAxis::atTop, mAxisRect, mColorAxis, mType, QCPAxis::orientation(), setDataRange(), setDataScaleType(), and type().

Referenced by QCPColorScale().

QCPAxis::AxisType type ( ) const

inline

Definition at line 2405 of file qcustomplot.h.

Referenced by QCPColorScaleAxisRectPrivate::draw(), and setType().

void update ( UpdatePhase phase )

virtual

Updates the layout element and sub-elements. This function is automatically called before every replot by the parent layout element. It is called multiple times, once for every UpdatePhase. The phases are run through in the order of the enum values. For details about what happens at the different phases, see the documentation of UpdatePhase.

Layout elements that have child elements should call the update method of their child elements, and pass the current phase unchanged.

The default implementation executes the automatic margin mechanism in the upMargins phase. Subclasses should make sure to call the base class implementation.

Reimplemented from QCPLayoutElement.

Definition at line 14122 of file qcustomplot.cpp.

References QCPAxis::atBottom, QCPAxis::atTop, QCPLayoutElement::margins(), mAxisRect, mBarWidth, mType, QCPLayoutElement::rect(), QCPLayoutElement::setMaximumSize(), QCPLayoutElement::setMinimumSize(), QCPLayoutElement::update(), QCPLayoutElement::upLayout, and QCPLayoutElement::upMargins.
