#include <qcustomplot.h>

Inheritance diagram for QCPItemBracket:

Collaboration diagram for QCPItemBracket:

Public Types
enum	BracketStyle { bsSquare, bsRound, bsCurly, bsCalligraphic }

Public Member Functions
	QCPItemBracket (QCustomPlot *parentPlot)

virtual	~QCPItemBracket ()

QPen	pen () const

QPen	selectedPen () const

double	length () const

BracketStyle	style () const

void	setPen (const QPen &pen)

void	setSelectedPen (const QPen &pen)

void	setLength (double length)

void	setStyle (BracketStyle style)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPAbstractItem
	QCPAbstractItem (QCustomPlot *parentPlot)

virtual	~QCPAbstractItem ()

bool	clipToAxisRect () const

QCPAxisRect *	clipAxisRect () const

bool	selectable () const

bool	selected () const

void	setClipToAxisRect (bool clip)

void	setClipAxisRect (QCPAxisRect *rect)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

QList< QCPItemPosition * >	positions () const

QList< QCPItemAnchor * >	anchors () const

QCPItemPosition *	position (const QString &name) const

QCPItemAnchor *	anchor (const QString &name) const

bool	hasAnchor (const QString &name) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Public Attributes
QCPItemPosition *const	left

QCPItemPosition *const	right

QCPItemAnchor *const	center

Protected Types
enum	AnchorIndex { aiCenter }

Protected Member Functions
virtual void	draw (QCPPainter *painter)

virtual QPointF	anchorPixelPoint (int anchorId) const

QPen	mainPen () const

Protected Member Functions inherited from QCPAbstractItem
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

double	distSqrToLine (const QPointF &start, const QPointF &end, const QPointF &point) const

double	rectSelectTest (const QRectF &rect, const QPointF &pos, bool filledRect) const

QCPItemPosition *	createPosition (const QString &name)

QCPItemAnchor *	createAnchor (const QString &name, int anchorId)

Protected Member Functions inherited from QCPLayerable
virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QPen	mPen

QPen	mSelectedPen

double	mLength

BracketStyle	mStyle

Protected Attributes inherited from QCPAbstractItem
bool	mClipToAxisRect

QPointer< QCPAxisRect >	mClipAxisRect

QList< QCPItemPosition * >	mPositions

QList< QCPItemAnchor * >	mAnchors

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Additional Inherited Members
Signals inherited from QCPAbstractItem
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Detailed Description

A bracket for referencing/highlighting certain parts in the plot.

Bracket example. Blue dotted circles are anchors, solid blue discs are positions.

It has two positions, left and right, which define the span of the bracket. If left is actually farther to the left than right, the bracket is opened to the bottom, as shown in the example image.

The bracket supports multiple styles via setStyle. The length, i.e. how far the bracket stretches away from the embraced span, can be controlled with setLength.

Demonstrating the effect of different values for setLength, for styles bsCalligraphic and bsSquare. Anchors and positions are displayed for reference.

It provides an anchor center, to allow connection of other items, e.g. an arrow (QCPItemLine or QCPItemCurve) or a text label (QCPItemText), to the bracket.

Definition at line 3714 of file qcustomplot.h.

Member Enumeration Documentation

enum AnchorIndex

protected

Enumerator
aiCenter

Definition at line 3754 of file qcustomplot.h.

enum BracketStyle

Enumerator
bsSquare	A brace with angled edges.
bsRound	A brace with round edges.
bsCurly	A curly brace.
bsCalligraphic	A curly brace with varying stroke width giving a calligraphic impression.

Definition at line 3724 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPItemBracket ( QCustomPlot * parentPlot )

Creates a bracket item and sets default values.

The constructed item can be added to the plot with QCustomPlot::addItem.

Definition at line 23347 of file qcustomplot.cpp.

References bsCalligraphic, left, right, QCPItemPosition::setCoords(), setLength(), setPen(), setSelectedPen(), and setStyle().

~QCPItemBracket ( )

virtual

Definition at line 23362 of file qcustomplot.cpp.

Member Function Documentation

QPointF anchorPixelPoint ( int anchorId ) const

protectedvirtual

Reimplemented from QCPAbstractItem.

Definition at line 23523 of file qcustomplot.cpp.

References aiCenter, left, mLength, QCPItemPosition::pixelPoint(), and right.

void draw ( QCPPainter * painter )

protectedvirtual

Implements QCPAbstractItem.

Definition at line 23454 of file qcustomplot.cpp.

References bsCalligraphic, bsCurly, bsRound, bsSquare, QCPAbstractItem::clipRect(), QCPPainter::drawLine(), left, mainPen(), mLength, mStyle, QCPItemPosition::pixelPoint(), right, and QCPPainter::setPen().

double length ( ) const

inline

Definition at line 3736 of file qcustomplot.h.

Referenced by setLength().

QPen mainPen ( ) const

protected

Definition at line 23549 of file qcustomplot.cpp.

References mPen, QCPAbstractItem::mSelected, and mSelectedPen.

Referenced by draw().

QPen pen ( ) const

inline

Definition at line 3734 of file qcustomplot.h.

Referenced by setPen(), and setSelectedPen().

QPen selectedPen ( ) const

inline

Definition at line 3735 of file qcustomplot.h.

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

This function is used to decide whether a click hits a layerable object or not.

pos is a point in pixel coordinates on the QCustomPlot surface. This function returns the shortest pixel distance of this point to the object. If the object is either invisible or the distance couldn't be determined, -1.0 is returned. Further, if onlySelectable is true and the object is not selectable, -1.0 is returned, too.

If the object is represented not by single lines but by an area like a QCPItemText or the bars of a QCPBars plottable, a click inside the area should also be considered a hit. In these cases this function thus returns a constant value greater zero but still below the parent plot's selection tolerance. (typically the selectionTolerance multiplied by 0.99).

Providing a constant value for area objects allows selecting line objects even when they are obscured by such area objects, by clicking close to the lines (i.e. closer than 0.99*selectionTolerance).

The actual setting of the selection state is not done by this function. This is handled by the parent QCustomPlot when the mouseReleaseEvent occurs, and the finally selected object is notified via the selectEvent/deselectEvent methods.

details is an optional output parameter. Every layerable subclass may place any information in details. This information will be passed to selectEvent when the parent QCustomPlot decides on the basis of this selectTest call, that the object was successfully selected. The subsequent call to selectEvent will carry the details. This is useful for multi-part objects (like QCPAxis). This way, a possibly complex calculation to decide which part was clicked is only done once in selectTest. The result (i.e. the actually clicked part) can then be placed in details. So in the subsequent selectEvent, the decision which part was selected doesn't have to be done a second time for a single selection operation.

You may pass 0 as details to indicate that you are not interested in those selection details.

See Also: selectEvent, deselectEvent, QCustomPlot::setInteractions

Implements QCPAbstractItem.

Definition at line 23414 of file qcustomplot.cpp.

References bsCalligraphic, bsCurly, bsRound, bsSquare, QCPAbstractItem::distSqrToLine(), left, mLength, QCPAbstractItem::mSelectable, mStyle, QCPItemPosition::pixelPoint(), and right.

void setLength ( double length )

Sets the length in pixels how far the bracket extends in the direction towards the embraced span of the bracket (i.e. perpendicular to the left-right-direction)

Demonstrating the effect of different values for setLength, for styles bsCalligraphic and bsSquare. Anchors and positions are displayed for reference.

Definition at line 23398 of file qcustomplot.cpp.

References length(), and mLength.

Referenced by QCPItemBracket().

void setPen ( const QPen & pen )

Sets the pen that will be used to draw the bracket.

Note that when the style is bsCalligraphic, only the color will be taken from the pen, the stroke and width are ignored. To change the apparent stroke width of a calligraphic bracket, use setLength, which has a similar effect.
