#include <qcustomplot.h>

Inheritance diagram for QCPItemCurve:

Collaboration diagram for QCPItemCurve:

Public Member Functions
	QCPItemCurve (QCustomPlot *parentPlot)

virtual	~QCPItemCurve ()

QPen	pen () const

QPen	selectedPen () const

QCPLineEnding	head () const

QCPLineEnding	tail () const

void	setPen (const QPen &pen)

void	setSelectedPen (const QPen &pen)

void	setHead (const QCPLineEnding &head)

void	setTail (const QCPLineEnding &tail)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPAbstractItem
	QCPAbstractItem (QCustomPlot *parentPlot)

virtual	~QCPAbstractItem ()

bool	clipToAxisRect () const

QCPAxisRect *	clipAxisRect () const

bool	selectable () const

bool	selected () const

void	setClipToAxisRect (bool clip)

void	setClipAxisRect (QCPAxisRect *rect)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

QList< QCPItemPosition * >	positions () const

QList< QCPItemAnchor * >	anchors () const

QCPItemPosition *	position (const QString &name) const

QCPItemAnchor *	anchor (const QString &name) const

bool	hasAnchor (const QString &name) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Public Attributes
QCPItemPosition *const	start

QCPItemPosition *const	startDir

QCPItemPosition *const	endDir

QCPItemPosition *const	end

Protected Member Functions
virtual void	draw (QCPPainter *painter)

QPen	mainPen () const

Protected Member Functions inherited from QCPAbstractItem
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

virtual QPointF	anchorPixelPoint (int anchorId) const

double	distSqrToLine (const QPointF &start, const QPointF &end, const QPointF &point) const

double	rectSelectTest (const QRectF &rect, const QPointF &pos, bool filledRect) const

QCPItemPosition *	createPosition (const QString &name)

QCPItemAnchor *	createAnchor (const QString &name, int anchorId)

Protected Member Functions inherited from QCPLayerable
virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QPen	mPen

QPen	mSelectedPen

QCPLineEnding	mHead

QCPLineEnding	mTail

Protected Attributes inherited from QCPAbstractItem
bool	mClipToAxisRect

QPointer< QCPAxisRect >	mClipAxisRect

QList< QCPItemPosition * >	mPositions

QList< QCPItemAnchor * >	mAnchors

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Additional Inherited Members
Signals inherited from QCPAbstractItem
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Detailed Description

A curved line from one point to another.

Curve example. Blue dotted circles are anchors, solid blue discs are positions.

It has four positions, start and end, which define the end points of the line, and two control points which define the direction the line exits from the start and the direction from which it approaches the end: startDir and endDir.

With setHead and setTail you may set different line ending styles, e.g. to create an arrow.

Often it is desirable for the control points to stay at fixed relative positions to the start/end point. This can be achieved by setting the parent anchor e.g. of startDir simply to start, and then specify the desired pixel offset with QCPItemPosition::setCoords on startDir.

Definition at line 3321 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPItemCurve ( QCustomPlot * parentPlot )

Creates a curve item and sets default values.

The constructed item can be added to the plot with QCustomPlot::addItem.

Definition at line 21896 of file qcustomplot.cpp.

References end, endDir, QCPItemPosition::setCoords(), setPen(), setSelectedPen(), start, and startDir.

~QCPItemCurve ( )

virtual

Definition at line 21912 of file qcustomplot.cpp.

Member Function Documentation

void draw ( QCPPainter * painter )

protectedvirtual

Implements QCPAbstractItem.

Definition at line 21989 of file qcustomplot.cpp.

References QCPAbstractItem::clipRect(), QCPLineEnding::draw(), end, endDir, QCPLineEnding::esNone, mainPen(), mHead, mTail, QCPItemPosition::pixelPoint(), QCPPainter::setPen(), start, startDir, and QCPLineEnding::style().

QCPLineEnding head ( ) const

inline

Definition at line 3337 of file qcustomplot.h.

Referenced by setHead().

QPen mainPen ( ) const

protected

Definition at line 22023 of file qcustomplot.cpp.

References mPen, QCPAbstractItem::mSelected, and mSelectedPen.

Referenced by draw().

QPen pen ( ) const

inline

Definition at line 3335 of file qcustomplot.h.

Referenced by setPen(), and setSelectedPen().

QPen selectedPen ( ) const

inline

Definition at line 3336 of file qcustomplot.h.

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

This function is used to decide whether a click hits a layerable object or not.

pos is a point in pixel coordinates on the QCustomPlot surface. This function returns the shortest pixel distance of this point to the object. If the object is either invisible or the distance couldn't be determined, -1.0 is returned. Further, if onlySelectable is true and the object is not selectable, -1.0 is returned, too.

If the object is represented not by single lines but by an area like a QCPItemText or the bars of a QCPBars plottable, a click inside the area should also be considered a hit. In these cases this function thus returns a constant value greater zero but still below the parent plot's selection tolerance. (typically the selectionTolerance multiplied by 0.99).

Providing a constant value for area objects allows selecting line objects even when they are obscured by such area objects, by clicking close to the lines (i.e. closer than 0.99*selectionTolerance).

The actual setting of the selection state is not done by this function. This is handled by the parent QCustomPlot when the mouseReleaseEvent occurs, and the finally selected object is notified via the selectEvent/deselectEvent methods.

details is an optional output parameter. Every layerable subclass may place any information in details. This information will be passed to selectEvent when the parent QCustomPlot decides on the basis of this selectTest call, that the object was successfully selected. The subsequent call to selectEvent will carry the details. This is useful for multi-part objects (like QCPAxis). This way, a possibly complex calculation to decide which part was clicked is only done once in selectTest. The result (i.e. the actually clicked part) can then be placed in details. So in the subsequent selectEvent, the decision which part was selected doesn't have to be done a second time for a single selection operation.

You may pass 0 as details to indicate that you are not interested in those selection details.
