#include <qcustomplot.h>

Inheritance diagram for QCPItemAnchor:

Collaboration diagram for QCPItemAnchor:

Public Member Functions
	QCPItemAnchor (QCustomPlot parentPlot, QCPAbstractItem parentItem, const QString name, int anchorId=-1)

virtual	~QCPItemAnchor ()

QString	name () const

virtual QPointF	pixelPoint () const

Protected Member Functions
virtual QCPItemPosition *	toQCPItemPosition ()

void	addChildX (QCPItemPosition *pos)

void	removeChildX (QCPItemPosition *pos)

void	addChildY (QCPItemPosition *pos)

void	removeChildY (QCPItemPosition *pos)

Protected Attributes
QString	mName

QCustomPlot *	mParentPlot

QCPAbstractItem *	mParentItem

int	mAnchorId

QSet< QCPItemPosition * >	mChildrenX

QSet< QCPItemPosition * >	mChildrenY

Friends
class	QCPItemPosition

Detailed Description

An anchor of an item to which positions can be attached to.

An item (QCPAbstractItem) may have one or more anchors. Unlike QCPItemPosition, an anchor doesn't control anything on its item, but provides a way to tie other items via their positions to the anchor.

For example, a QCPItemRect is defined by its positions topLeft and bottomRight. Additionally it has various anchors like top, topRight or bottomLeft etc. So you can attach the start (which is a QCPItemPosition) of a QCPItemLine to one of the anchors by calling QCPItemPosition::setParentAnchor on start, passing the wanted anchor of the QCPItemRect. This way the start of the line will now always follow the respective anchor location on the rect item.

Note that QCPItemPosition derives from QCPItemAnchor, so every position can also serve as an anchor to other positions.

To learn how to provide anchors in your own item subclasses, see the subclassing section of the QCPAbstractItem documentation.

Definition at line 1503 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPItemAnchor	(	QCustomPlot *	parentPlot,
		QCPAbstractItem *	parentItem,
		const QString	name,
		int	anchorId = `-1`
	)

Creates a new QCPItemAnchor. You shouldn't create QCPItemAnchor instances directly, even if you want to make a new item subclass. Use QCPAbstractItem::createAnchor instead, as explained in the subclassing section of the QCPAbstractItem documentation.

Definition at line 7452 of file qcustomplot.cpp.

~QCPItemAnchor ( )

virtual

Definition at line 7460 of file qcustomplot.cpp.

References mChildrenX, mChildrenY, QCPItemPosition::parentAnchorX(), QCPItemPosition::parentAnchorY(), QCPItemPosition::setParentAnchorX(), and QCPItemPosition::setParentAnchorY().

Member Function Documentation

void addChildX ( QCPItemPosition * pos )

protected

Definition at line 7508 of file qcustomplot.cpp.

References mChildrenX.

Referenced by QCPItemPosition::setParentAnchorX().

void addChildY ( QCPItemPosition * pos )

protected

Definition at line 7536 of file qcustomplot.cpp.

References mChildrenY.

Referenced by QCPItemPosition::setParentAnchorY().

QString name ( ) const

inline

Definition at line 1510 of file qcustomplot.h.

QPointF pixelPoint ( ) const

virtual

Returns the final absolute pixel position of the QCPItemAnchor on the QCustomPlot surface.

The pixel information is internally retrieved via QCPAbstractItem::anchorPixelPosition of the parent item, QCPItemAnchor is just an intermediary.

Reimplemented in QCPItemPosition.

Definition at line 7481 of file qcustomplot.cpp.

References QCPAbstractItem::anchorPixelPoint(), mAnchorId, and mParentItem.

Referenced by QCPItemPosition::pixelPoint(), and QCPItemPosition::setPixelPoint().

void removeChildX ( QCPItemPosition * pos )

protected

Definition at line 7522 of file qcustomplot.cpp.

References mChildrenX.

Referenced by QCPItemPosition::setParentAnchorX(), and QCPItemPosition::~QCPItemPosition().

void removeChildY ( QCPItemPosition * pos )

protected

Definition at line 7550 of file qcustomplot.cpp.

References mChildrenY.

Referenced by QCPItemPosition::setParentAnchorY(), and QCPItemPosition::~QCPItemPosition().

QCPItemPosition * toQCPItemPosition ( )

inlineprotectedvirtual

Returns 0 if this instance is merely a QCPItemAnchor, and a valid pointer of type QCPItemPosition* if it actually is a QCPItemPosition (which is a subclass of QCPItemAnchor).

This safe downcast functionality could also be achieved with a dynamic_cast. However, QCustomPlot avoids dynamic_cast to work with projects that don't have RTTI support enabled (e.g. -fno-rtti flag with gcc compiler).

Reimplemented in QCPItemPosition.

Definition at line 1524 of file qcustomplot.h.

Referenced by QCPItemPosition::setParentAnchorX(), and QCPItemPosition::setParentAnchorY().
