#include <qcustomplot.h>

Inheritance diagram for QCPItemText:

Collaboration diagram for QCPItemText:

Public Member Functions
	QCPItemText (QCustomPlot *parentPlot)

virtual	~QCPItemText ()

QColor	color () const

QColor	selectedColor () const

QPen	pen () const

QPen	selectedPen () const

QBrush	brush () const

QBrush	selectedBrush () const

QFont	font () const

QFont	selectedFont () const

QString	text () const

Qt::Alignment	positionAlignment () const

Qt::Alignment	textAlignment () const

double	rotation () const

QMargins	padding () const

void	setColor (const QColor &color)

void	setSelectedColor (const QColor &color)

void	setPen (const QPen &pen)

void	setSelectedPen (const QPen &pen)

void	setBrush (const QBrush &brush)

void	setSelectedBrush (const QBrush &brush)

void	setFont (const QFont &font)

void	setSelectedFont (const QFont &font)

void	setText (const QString &text)

void	setPositionAlignment (Qt::Alignment alignment)

void	setTextAlignment (Qt::Alignment alignment)

void	setRotation (double degrees)

void	setPadding (const QMargins &padding)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPAbstractItem
	QCPAbstractItem (QCustomPlot *parentPlot)

virtual	~QCPAbstractItem ()

bool	clipToAxisRect () const

QCPAxisRect *	clipAxisRect () const

bool	selectable () const

bool	selected () const

void	setClipToAxisRect (bool clip)

void	setClipAxisRect (QCPAxisRect *rect)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

QList< QCPItemPosition * >	positions () const

QList< QCPItemAnchor * >	anchors () const

QCPItemPosition *	position (const QString &name) const

QCPItemAnchor *	anchor (const QString &name) const

bool	hasAnchor (const QString &name) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Public Attributes
QCPItemPosition *const	position

QCPItemAnchor *const	topLeft

QCPItemAnchor *const	top

QCPItemAnchor *const	topRight

QCPItemAnchor *const	right

QCPItemAnchor *const	bottomRight

QCPItemAnchor *const	bottom

QCPItemAnchor *const	bottomLeft

QCPItemAnchor *const	left

Protected Types
enum	AnchorIndex { aiTopLeft, aiTop, aiTopRight, aiRight, aiBottomRight, aiBottom, aiBottomLeft, aiLeft }

Protected Member Functions
virtual void	draw (QCPPainter *painter)

virtual QPointF	anchorPixelPoint (int anchorId) const

QPointF	getTextDrawPoint (const QPointF &pos, const QRectF &rect, Qt::Alignment positionAlignment) const

QFont	mainFont () const

QColor	mainColor () const

QPen	mainPen () const

QBrush	mainBrush () const

Protected Member Functions inherited from QCPAbstractItem
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

double	distSqrToLine (const QPointF &start, const QPointF &end, const QPointF &point) const

double	rectSelectTest (const QRectF &rect, const QPointF &pos, bool filledRect) const

QCPItemPosition *	createPosition (const QString &name)

QCPItemAnchor *	createAnchor (const QString &name, int anchorId)

Protected Member Functions inherited from QCPLayerable
virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QColor	mColor

QColor	mSelectedColor

QPen	mPen

QPen	mSelectedPen

QBrush	mBrush

QBrush	mSelectedBrush

QFont	mFont

QFont	mSelectedFont

QString	mText

Qt::Alignment	mPositionAlignment

Qt::Alignment	mTextAlignment

double	mRotation

QMargins	mPadding

Protected Attributes inherited from QCPAbstractItem
bool	mClipToAxisRect

QPointer< QCPAxisRect >	mClipAxisRect

QList< QCPItemPosition * >	mPositions

QList< QCPItemAnchor * >	mAnchors

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Additional Inherited Members
Signals inherited from QCPAbstractItem
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Detailed Description

A text label.

Text example. Blue dotted circles are anchors, solid blue discs are positions.

Its position is defined by the member position and the setting of setPositionAlignment. The latter controls which part of the text rect shall be aligned with position.

The text alignment itself (i.e. left, center, right) can be controlled with setTextAlignment.

The text may be rotated around the position point with setRotation.

Definition at line 3421 of file qcustomplot.h.

Member Enumeration Documentation

enum AnchorIndex

protected

Enumerator
aiTopLeft
aiTop
aiTopRight
aiRight
aiBottomRight
aiBottom
aiBottomLeft
aiLeft

Definition at line 3487 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPItemText ( QCustomPlot * parentPlot )

Creates a text item and sets default values.

The constructed item can be added to the plot with QCustomPlot::addItem.

Definition at line 22204 of file qcustomplot.cpp.

References position, setBrush(), setColor(), QCPItemPosition::setCoords(), setPen(), setPositionAlignment(), setRotation(), setSelectedBrush(), setSelectedColor(), setSelectedPen(), setText(), and setTextAlignment().

~QCPItemText ( )

virtual

Definition at line 22231 of file qcustomplot.cpp.

Member Function Documentation

QPointF anchorPixelPoint ( int anchorId ) const

protectedvirtual

Reimplemented from QCPAbstractItem.

Definition at line 22426 of file qcustomplot.cpp.

References aiBottom, aiBottomLeft, aiBottomRight, aiLeft, aiRight, aiTop, aiTopLeft, aiTopRight, getTextDrawPoint(), mainFont(), mPadding, mPositionAlignment, mRotation, mText, mTextAlignment, QCPItemPosition::pixelPoint(), and position.

QBrush brush ( ) const

inline

Definition at line 3448 of file qcustomplot.h.

Referenced by setBrush(), and setSelectedBrush().

QColor color ( ) const

inline

Definition at line 3444 of file qcustomplot.h.

Referenced by draw(), setColor(), and setSelectedColor().

void draw ( QCPPainter * painter )

protectedvirtual

Implements QCPAbstractItem.

Definition at line 22394 of file qcustomplot.cpp.

References QCPAbstractItem::clipRect(), color(), getTextDrawPoint(), mainBrush(), mainColor(), mainFont(), mainPen(), mPadding, mPositionAlignment, mRotation, mText, mTextAlignment, QCPItemPosition::pixelPoint(), position, and QCPPainter::setPen().

QFont font ( ) const

inline

Definition at line 3450 of file qcustomplot.h.

Referenced by setFont(), and setSelectedFont().

QPointF getTextDrawPoint	(	const QPointF &	pos,
		const QRectF &	rect,
		Qt::Alignment	positionAlignment
	)		const

protected

Definition at line 22467 of file qcustomplot.cpp.

Referenced by anchorPixelPoint(), draw(), and selectTest().

QBrush mainBrush ( ) const

protected

Definition at line 22519 of file qcustomplot.cpp.

References mBrush, QCPAbstractItem::mSelected, and mSelectedBrush.

Referenced by draw().

QColor mainColor ( ) const

protected

Definition at line 22499 of file qcustomplot.cpp.

References mColor, QCPAbstractItem::mSelected, and mSelectedColor.

Referenced by draw().

QFont mainFont ( ) const

protected

Definition at line 22489 of file qcustomplot.cpp.

References mFont, QCPAbstractItem::mSelected, and mSelectedFont.

Referenced by anchorPixelPoint(), and draw().

QPen mainPen ( ) const

protected

Definition at line 22509 of file qcustomplot.cpp.

References mPen, QCPAbstractItem::mSelected, and mSelectedPen.

Referenced by draw().

QMargins padding ( ) const

inline

Definition at line 3456 of file qcustomplot.h.

Referenced by setPadding().

QPen pen ( ) const

inline

Definition at line 3446 of file qcustomplot.h.

Referenced by setPen(), and setSelectedPen().

Qt::Alignment positionAlignment ( ) const

inline

Definition at line 3453 of file qcustomplot.h.

double rotation ( ) const

inline

Definition at line 3455 of file qcustomplot.h.

QBrush selectedBrush ( ) const

inline

Definition at line 3449 of file qcustomplot.h.

QColor selectedColor ( ) const

inline

Definition at line 3445 of file qcustomplot.h.

QFont selectedFont ( ) const

inline

Definition at line 3451 of file qcustomplot.h.

QPen selectedPen ( ) const

inline

Definition at line 3447 of file qcustomplot.h.

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

This function is used to decide whether a click hits a layerable object or not.

pos is a point in pixel coordinates on the QCustomPlot surface. This function returns the shortest pixel distance of this point to the object. If the object is either invisible or the distance couldn't be determined, -1.0 is returned. Further, if onlySelectable is true and the object is not selectable, -1.0 is returned, too.

If the object is represented not by single lines but by an area like a QCPItemText or the bars of a QCPBars plottable, a click inside the area should also be considered a hit. In these cases this function thus returns a constant value greater zero but still below the parent plot's selection tolerance. (typically the selectionTolerance multiplied by 0.99).

Providing a constant value for area objects allows selecting line objects even when they are obscured by such area objects, by clicking close to the lines (i.e. closer than 0.99*selectionTolerance).

The actual setting of the selection state is not done by this function. This is handled by the parent QCustomPlot when the mouseReleaseEvent occurs, and the finally selected object is notified via the selectEvent/deselectEvent methods.

details is an optional output parameter. Every layerable subclass may place any information in details. This information will be passed to selectEvent when the parent QCustomPlot decides on the basis of this selectTest call, that the object was successfully selected. The subsequent call to selectEvent will carry the details. This is useful for multi-part objects (like QCPAxis). This way, a possibly complex calculation to decide which part was clicked is only done once in selectTest. The result (i.e. the actually clicked part) can then be placed in details. So in the subsequent selectEvent, the decision which part was selected doesn't have to be done a second time for a single selection operation.

You may pass 0 as details to indicate that you are not interested in those selection details.

See Also: selectEvent, deselectEvent, QCustomPlot::setInteractions

Implements QCPAbstractItem.

Definition at line 22370 of file qcustomplot.cpp.

References getTextDrawPoint(), mFont, mPadding, mPositionAlignment, mRotation, QCPAbstractItem::mSelectable, mText, mTextAlignment, QCPItemPosition::pixelPoint(), position, and QCPAbstractItem::rectSelectTest().

void setBrush ( const QBrush & brush )

Sets the brush that will be used do fill the background of the text. To disable the background, set brush to Qt::NoBrush.

See Also: setSelectedBrush, setPen, setPadding

Definition at line 22279 of file qcustomplot.cpp.

References brush(), and mBrush.

Referenced by QCPItemText().

void setColor ( const QColor & color )

Sets the color of the text.

Definition at line 22238 of file qcustomplot.cpp.

References color(), and mColor.

Referenced by QCPItemText().

void setFont ( const QFont & font )

Sets the font of the text.

See Also: setSelectedFont, setColor

Definition at line 22300 of file qcustomplot.cpp.

References font(), and mFont.

void setPadding ( const QMargins & padding )

Sets the distance between the border of the text rectangle and the text. The appearance (and visibility) of the text rectangle can be controlled with setPen and setBrush.

Definition at line 22364 of file qcustomplot.cpp.

References mPadding, and padding().

void setPen ( const QPen & pen )

Sets the pen that will be used do draw a rectangular border around the text. To disable the border, set pen to Qt::NoPen.

See Also: setSelectedPen, setBrush, setPadding

Definition at line 22257 of file qcustomplot.cpp.

References mPen, and pen().

Referenced by QCPItemText().

void setPositionAlignment ( Qt::Alignment alignment )

Sets which point of the text rect shall be aligned with position.

Examples:

If alignment is Qt::AlignHCenter | Qt::AlignTop, the text will be positioned such that the top of the text rect will be horizontally centered on position.
If alignment is Qt::AlignLeft | Qt::AlignBottom, position will indicate the bottom left corner of the text rect.

If you want to control the alignment of (multi-lined) text within the text rect, use setTextAlignment.

Definition at line 22338 of file qcustomplot.cpp.

References mPositionAlignment.

Referenced by QCPItemText().

void setRotation ( double degrees )

Sets the angle in degrees by which the text (and the text rectangle, if visible) will be rotated around position.

Definition at line 22355 of file qcustomplot.cpp.

References mRotation.

Referenced by QCPItemText().

void setSelectedBrush ( const QBrush & brush )

Sets the brush that will be used do fill the background of the text, when the item is selected. To disable the background, set brush to Qt::NoBrush.

See Also: setBrush

Definition at line 22290 of file qcustomplot.cpp.

References brush(), and mSelectedBrush.

Referenced by QCPItemText().

void setSelectedColor ( const QColor & color )

Sets the color of the text that will be used when the item is selected.

Definition at line 22246 of file qcustomplot.cpp.

References color(), and mSelectedColor.

Referenced by QCPItemText().

void setSelectedFont ( const QFont & font )

Sets the font of the text that will be used when the item is selected.

See Also: setFont

Definition at line 22310 of file qcustomplot.cpp.

References font(), and mSelectedFont.

void setSelectedPen ( const QPen & pen )

Sets the pen that will be used do draw a rectangular border around the text, when the item is selected. To disable the border, set pen to Qt::NoPen.
