#include <qcustomplot.h>

Inheritance diagram for QCPItemPixmap:

Collaboration diagram for QCPItemPixmap:

Public Member Functions
	QCPItemPixmap (QCustomPlot *parentPlot)

virtual	~QCPItemPixmap ()

QPixmap	pixmap () const

bool	scaled () const

Qt::AspectRatioMode	aspectRatioMode () const

Qt::TransformationMode	transformationMode () const

QPen	pen () const

QPen	selectedPen () const

void	setPixmap (const QPixmap &pixmap)

void	setScaled (bool scaled, Qt::AspectRatioMode aspectRatioMode=Qt::KeepAspectRatio, Qt::TransformationMode transformationMode=Qt::SmoothTransformation)

void	setPen (const QPen &pen)

void	setSelectedPen (const QPen &pen)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPAbstractItem
	QCPAbstractItem (QCustomPlot *parentPlot)

virtual	~QCPAbstractItem ()

bool	clipToAxisRect () const

QCPAxisRect *	clipAxisRect () const

bool	selectable () const

bool	selected () const

void	setClipToAxisRect (bool clip)

void	setClipAxisRect (QCPAxisRect *rect)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

QList< QCPItemPosition * >	positions () const

QList< QCPItemAnchor * >	anchors () const

QCPItemPosition *	position (const QString &name) const

QCPItemAnchor *	anchor (const QString &name) const

bool	hasAnchor (const QString &name) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Public Attributes
QCPItemPosition *const	topLeft

QCPItemPosition *const	bottomRight

QCPItemAnchor *const	top

QCPItemAnchor *const	topRight

QCPItemAnchor *const	right

QCPItemAnchor *const	bottom

QCPItemAnchor *const	bottomLeft

QCPItemAnchor *const	left

Protected Types
enum	AnchorIndex { aiTop, aiTopRight, aiRight, aiBottom, aiBottomLeft, aiLeft }

Protected Member Functions
virtual void	draw (QCPPainter *painter)

virtual QPointF	anchorPixelPoint (int anchorId) const

void	updateScaledPixmap (QRect finalRect=QRect(), bool flipHorz=false, bool flipVert=false)

QRect	getFinalRect (bool flippedHorz=0, bool flippedVert=0) const

QPen	mainPen () const

Protected Member Functions inherited from QCPAbstractItem
virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

double	distSqrToLine (const QPointF &start, const QPointF &end, const QPointF &point) const

double	rectSelectTest (const QRectF &rect, const QPointF &pos, bool filledRect) const

QCPItemPosition *	createPosition (const QString &name)

QCPItemAnchor *	createAnchor (const QString &name, int anchorId)

Protected Member Functions inherited from QCPLayerable
virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QPixmap	mPixmap

QPixmap	mScaledPixmap

bool	mScaled

bool	mScaledPixmapInvalidated

Qt::AspectRatioMode	mAspectRatioMode

Qt::TransformationMode	mTransformationMode

QPen	mPen

QPen	mSelectedPen

Protected Attributes inherited from QCPAbstractItem
bool	mClipToAxisRect

QPointer< QCPAxisRect >	mClipAxisRect

QList< QCPItemPosition * >	mPositions

QList< QCPItemAnchor * >	mAnchors

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Additional Inherited Members
Signals inherited from QCPAbstractItem
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Detailed Description

An arbitrary pixmap.

Pixmap example. Blue dotted circles are anchors, solid blue discs are positions.

It has two positions, topLeft and bottomRight, which define the rectangle the pixmap will be drawn in. Depending on the scale setting (setScaled), the pixmap will be either scaled to fit the rectangle or be drawn aligned to the topLeft position.

If scaling is enabled and topLeft is further to the bottom/right than bottomRight (as shown on the right side of the example image), the pixmap will be flipped in the respective orientations.

Definition at line 3570 of file qcustomplot.h.

Member Enumeration Documentation

enum AnchorIndex

protected

Enumerator
aiTop
aiTopRight
aiRight
aiBottom
aiBottomLeft
aiLeft

Definition at line 3612 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPItemPixmap ( QCustomPlot * parentPlot )

Creates a rectangle item and sets default values.

The constructed item can be added to the plot with QCustomPlot::addItem.

Definition at line 22732 of file qcustomplot.cpp.

References bottomRight, QCPItemPosition::setCoords(), setPen(), setScaled(), setSelectedPen(), and topLeft.

~QCPItemPixmap ( )

virtual

Definition at line 22752 of file qcustomplot.cpp.

Member Function Documentation

QPointF anchorPixelPoint ( int anchorId ) const

protectedvirtual

Reimplemented from QCPAbstractItem.

Definition at line 22832 of file qcustomplot.cpp.

References aiBottom, aiBottomLeft, aiLeft, aiRight, aiTop, aiTopRight, and getFinalRect().

Qt::AspectRatioMode aspectRatioMode ( ) const

inline

Definition at line 3588 of file qcustomplot.h.

Referenced by setScaled().

void draw ( QCPPainter * painter )

protectedvirtual

Implements QCPAbstractItem.

Definition at line 22810 of file qcustomplot.cpp.

References QCPAbstractItem::clipRect(), getFinalRect(), mainPen(), mPixmap, mScaled, mScaledPixmap, pen(), QCPPainter::setPen(), and updateScaledPixmap().

QRect getFinalRect	(	bool *	flippedHorz = `0`,
		bool *	flippedVert = `0`
	)		const

protected

Definition at line 22905 of file qcustomplot.cpp.

References bottomRight, mAspectRatioMode, mPixmap, mScaled, QCPItemPosition::pixelPoint(), and topLeft.

Referenced by anchorPixelPoint(), draw(), selectTest(), and updateScaledPixmap().

QPen mainPen ( ) const

protected

Definition at line 22949 of file qcustomplot.cpp.

References mPen, QCPAbstractItem::mSelected, and mSelectedPen.

Referenced by draw().

QPen pen ( ) const

inline

Definition at line 3590 of file qcustomplot.h.

Referenced by draw(), setPen(), and setSelectedPen().

QPixmap pixmap ( ) const

inline

Definition at line 3586 of file qcustomplot.h.

Referenced by setPixmap().

bool scaled ( ) const

inline

Definition at line 3587 of file qcustomplot.h.

Referenced by setScaled().

QPen selectedPen ( ) const

inline

Definition at line 3591 of file qcustomplot.h.

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

This function is used to decide whether a click hits a layerable object or not.

pos is a point in pixel coordinates on the QCustomPlot surface. This function returns the shortest pixel distance of this point to the object. If the object is either invisible or the distance couldn't be determined, -1.0 is returned. Further, if onlySelectable is true and the object is not selectable, -1.0 is returned, too.

If the object is represented not by single lines but by an area like a QCPItemText or the bars of a QCPBars plottable, a click inside the area should also be considered a hit. In these cases this function thus returns a constant value greater zero but still below the parent plot's selection tolerance. (typically the selectionTolerance multiplied by 0.99).

Providing a constant value for area objects allows selecting line objects even when they are obscured by such area objects, by clicking close to the lines (i.e. closer than 0.99*selectionTolerance).

The actual setting of the selection state is not done by this function. This is handled by the parent QCustomPlot when the mouseReleaseEvent occurs, and the finally selected object is notified via the selectEvent/deselectEvent methods.

details is an optional output parameter. Every layerable subclass may place any information in details. This information will be passed to selectEvent when the parent QCustomPlot decides on the basis of this selectTest call, that the object was successfully selected. The subsequent call to selectEvent will carry the details. This is useful for multi-part objects (like QCPAxis). This way, a possibly complex calculation to decide which part was clicked is only done once in selectTest. The result (i.e. the actually clicked part) can then be placed in details. So in the subsequent selectEvent, the decision which part was selected doesn't have to be done a second time for a single selection operation.

You may pass 0 as details to indicate that you are not interested in those selection details.

See Also: selectEvent, deselectEvent, QCustomPlot::setInteractions

Implements QCPAbstractItem.

Definition at line 22800 of file qcustomplot.cpp.

References getFinalRect(), QCPAbstractItem::mSelectable, and QCPAbstractItem::rectSelectTest().

void setPen ( const QPen & pen )

Sets the pen that will be used to draw a border around the pixmap.

See Also: setSelectedPen, setBrush

Definition at line 22784 of file qcustomplot.cpp.

References mPen, and pen().

Referenced by QCPItemPixmap().

void setPixmap ( const QPixmap & pixmap )

Sets the pixmap that will be displayed.

Definition at line 22759 of file qcustomplot.cpp.

References mPixmap, mScaledPixmapInvalidated, and pixmap().

void setScaled	(	bool	scaled,
		Qt::AspectRatioMode	aspectRatioMode = `Qt::KeepAspectRatio`,
		Qt::TransformationMode	transformationMode = `Qt::SmoothTransformation`
	)
