Collaboration diagram for QCPStatisticalBox:

Public Member Functions
	QCPStatisticalBox (QCPAxis keyAxis, QCPAxis valueAxis)

double	key () const

double	minimum () const

double	lowerQuartile () const

double	median () const

double	upperQuartile () const

double	maximum () const

QVector< double >	outliers () const

double	width () const

double	whiskerWidth () const

QPen	whiskerPen () const

QPen	whiskerBarPen () const

QPen	medianPen () const

QCPScatterStyle	outlierStyle () const

void	setKey (double key)

void	setMinimum (double value)

void	setLowerQuartile (double value)

void	setMedian (double value)

void	setUpperQuartile (double value)

void	setMaximum (double value)

void	setOutliers (const QVector< double > &values)

void	setData (double key, double minimum, double lowerQuartile, double median, double upperQuartile, double maximum)

void	setWidth (double width)

void	setWhiskerWidth (double width)

void	setWhiskerPen (const QPen &pen)

void	setWhiskerBarPen (const QPen &pen)

void	setMedianPen (const QPen &pen)

void	setOutlierStyle (const QCPScatterStyle &style)

virtual void	clearData ()

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

Public Member Functions inherited from QCPAbstractPlottable
	QCPAbstractPlottable (QCPAxis keyAxis, QCPAxis valueAxis)

QString	name () const

bool	antialiasedFill () const

bool	antialiasedScatters () const

bool	antialiasedErrorBars () const

QPen	pen () const

QPen	selectedPen () const

QBrush	brush () const

QBrush	selectedBrush () const

QCPAxis *	keyAxis () const

QCPAxis *	valueAxis () const

bool	selectable () const

bool	selected () const

void	setName (const QString &name)

void	setAntialiasedFill (bool enabled)

void	setAntialiasedScatters (bool enabled)

void	setAntialiasedErrorBars (bool enabled)

void	setPen (const QPen &pen)

void	setSelectedPen (const QPen &pen)

void	setBrush (const QBrush &brush)

void	setSelectedBrush (const QBrush &brush)

void	setKeyAxis (QCPAxis *axis)

void	setValueAxis (QCPAxis *axis)

Q_SLOT void	setSelectable (bool selectable)

Q_SLOT void	setSelected (bool selected)

virtual bool	addToLegend ()

virtual bool	removeFromLegend () const

void	rescaleAxes (bool onlyEnlarge=false) const

void	rescaleKeyAxis (bool onlyEnlarge=false) const

void	rescaleValueAxis (bool onlyEnlarge=false) const

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

bool	realVisibility () const

Protected Member Functions
virtual void	draw (QCPPainter *painter)

virtual void	drawLegendIcon (QCPPainter *painter, const QRectF &rect) const

virtual QCPRange	getKeyRange (bool &foundRange, SignDomain inSignDomain=sdBoth) const

virtual QCPRange	getValueRange (bool &foundRange, SignDomain inSignDomain=sdBoth) const

virtual void	drawQuartileBox (QCPPainter painter, QRectF quartileBox=0) const

virtual void	drawMedian (QCPPainter *painter) const

virtual void	drawWhiskers (QCPPainter *painter) const

virtual void	drawOutliers (QCPPainter *painter) const

Protected Member Functions inherited from QCPAbstractPlottable
virtual QRect	clipRect () const

virtual QCP::Interaction	selectionCategory () const

void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

void	coordsToPixels (double key, double value, double &x, double &y) const

const QPointF	coordsToPixels (double key, double value) const

void	pixelsToCoords (double x, double y, double &key, double &value) const

void	pixelsToCoords (const QPointF &pixelPos, double &key, double &value) const

QPen	mainPen () const

QBrush	mainBrush () const

void	applyFillAntialiasingHint (QCPPainter *painter) const

void	applyScattersAntialiasingHint (QCPPainter *painter) const

void	applyErrorBarsAntialiasingHint (QCPPainter *painter) const

double	distSqrToLine (const QPointF &start, const QPointF &end, const QPointF &point) const

Protected Member Functions inherited from QCPLayerable
virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
QVector< double >	mOutliers

double	mKey

double	mMinimum

double	mLowerQuartile

double	mMedian

double	mUpperQuartile

double	mMaximum

double	mWidth

double	mWhiskerWidth

QPen	mWhiskerPen

QPen	mWhiskerBarPen

QPen	mMedianPen

QCPScatterStyle	mOutlierStyle

Protected Attributes inherited from QCPAbstractPlottable
QString	mName

bool	mAntialiasedFill

bool	mAntialiasedScatters

bool	mAntialiasedErrorBars

QPen	mPen

QPen	mSelectedPen

QBrush	mBrush

QBrush	mSelectedBrush

QPointer< QCPAxis >	mKeyAxis

QPointer< QCPAxis >	mValueAxis

bool	mSelectable

bool	mSelected

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Friends
class	QCustomPlot

class	QCPLegend

Additional Inherited Members
Signals inherited from QCPAbstractPlottable
void	selectionChanged (bool selected)

void	selectableChanged (bool selectable)

Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Protected Types inherited from QCPAbstractPlottable
enum	SignDomain { sdNegative, sdBoth, sdPositive }

Detailed Description

A plottable representing a single statistical box in a plot.

To plot data, assign it with the individual parameter functions or use setData to set all parameters at once. The individual functions are:

Additionally you can define a list of outliers, drawn as scatter datapoints:

setOutliers

Changing the appearance

The appearance of the box itself is controlled via setPen and setBrush. You may change the width of the box with setWidth in plot coordinates (not pixels).

Analog functions exist for the minimum/maximum-whiskers: setWhiskerPen, setWhiskerBarPen, setWhiskerWidth. The whisker width is the width of the bar at the top (maximum) and bottom (minimum).

The median indicator line has its own pen, setMedianPen.

If the whisker backbone pen is changed, make sure to set the capStyle to Qt::FlatCap. Else, the backbone line might exceed the whisker bars by a few pixels due to the pen cap being not perfectly flat.

The Outlier data points are drawn as normal scatter points. Their look can be controlled with setOutlierStyle

Usage

Like all data representing objects in QCustomPlot, the QCPStatisticalBox is a plottable. Usually, you first create an instance and add it to the customPlot:

and then modify the properties of the newly created plottable, e.g.:

Definition at line 2915 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPStatisticalBox	(	QCPAxis *	keyAxis,
		QCPAxis *	valueAxis
	)

explicit

Constructs a statistical box which uses keyAxis as its key axis ("x") and valueAxis as its value axis ("y"). keyAxis and valueAxis must reside in the same QCustomPlot instance and not have the same orientation. If either of these restrictions is violated, a corresponding message is printed to the debug output (qDebug), the construction is not aborted, though.

The constructed statistical box can be added to the plot with QCustomPlot::addPlottable, QCustomPlot then takes ownership of the statistical box.

Definition at line 19188 of file qcustomplot.cpp.

References QCPAbstractPlottable::setBrush(), setMedianPen(), setOutlierStyle(), QCPAbstractPlottable::setPen(), QCPAbstractPlottable::setSelectedBrush(), QCPAbstractPlottable::setSelectedPen(), setWhiskerBarPen(), setWhiskerPen(), setWhiskerWidth(), setWidth(), and QCPScatterStyle::ssCircle.

Member Function Documentation

void clearData ( )

virtual

Clears all data in the plottable.

Implements QCPAbstractPlottable.

Definition at line 19366 of file qcustomplot.cpp.

References setKey(), setLowerQuartile(), setMaximum(), setMedian(), setMinimum(), setOutliers(), and setUpperQuartile().

void draw ( QCPPainter * painter )

protectedvirtual

Implements QCPAbstractPlottable.

Definition at line 19403 of file qcustomplot.cpp.

References drawMedian(), drawOutliers(), drawQuartileBox(), drawWhiskers(), QCP::isInvalidData(), mKey, QCPAbstractPlottable::mKeyAxis, mLowerQuartile, mMaximum, mMedian, mMinimum, mOutliers, mUpperQuartile, QCPAbstractPlottable::mValueAxis, QCPAbstractPlottable::name(), QCPPainter::restore(), and QCPPainter::save().

void drawLegendIcon	(	QCPPainter *	painter,
		const QRectF &	rect
	)		const

protectedvirtual

Implements QCPAbstractPlottable.

Definition at line 19431 of file qcustomplot.cpp.

References QCPAbstractPlottable::applyDefaultAntialiasingHint(), QCPAbstractPlottable::mBrush, QCPAbstractPlottable::mPen, and QCPPainter::setPen().

void drawMedian ( QCPPainter * painter ) const

protectedvirtual

Definition at line 19465 of file qcustomplot.cpp.

References QCPAbstractPlottable::applyDefaultAntialiasingHint(), QCPAbstractPlottable::coordsToPixels(), QCPPainter::drawLine(), mKey, mMedian, mMedianPen, mWidth, and QCPPainter::setPen().

Referenced by draw().

void drawOutliers ( QCPPainter * painter ) const

protectedvirtual

Definition at line 19499 of file qcustomplot.cpp.

References QCPAbstractPlottable::applyScattersAntialiasingHint(), QCPScatterStyle::applyTo(), QCPAbstractPlottable::coordsToPixels(), QCPScatterStyle::drawShape(), mKey, mOutliers, mOutlierStyle, and QCPAbstractPlottable::mPen.

Referenced by draw().

void drawQuartileBox	(	QCPPainter *	painter,
		QRectF *	quartileBox = `0`
	)		const

protectedvirtual

Definition at line 19448 of file qcustomplot.cpp.

References QCPAbstractPlottable::applyDefaultAntialiasingHint(), QCPAbstractPlottable::coordsToPixels(), QCPAbstractPlottable::mainBrush(), QCPAbstractPlottable::mainPen(), mKey, mLowerQuartile, mUpperQuartile, mWidth, and QCPPainter::setPen().

Referenced by draw().

void drawWhiskers ( QCPPainter * painter ) const

protectedvirtual

Definition at line 19479 of file qcustomplot.cpp.

References QCPAbstractPlottable::applyErrorBarsAntialiasingHint(), QCPAbstractPlottable::coordsToPixels(), QCPPainter::drawLine(), mKey, mLowerQuartile, mMaximum, mMinimum, mUpperQuartile, mWhiskerBarPen, mWhiskerPen, mWhiskerWidth, and QCPPainter::setPen().

Referenced by draw().

QCPRange getKeyRange	(	bool &	foundRange,
		SignDomain	inSignDomain = `sdBoth`
	)		const

protectedvirtual

Implements QCPAbstractPlottable.

Definition at line 19508 of file qcustomplot.cpp.

References mKey, mWidth, QCPAbstractPlottable::sdBoth, QCPAbstractPlottable::sdNegative, and QCPAbstractPlottable::sdPositive.

QCPRange getValueRange	(	bool &	foundRange,
		SignDomain	inSignDomain = `sdBoth`
	)		const

protectedvirtual

Implements QCPAbstractPlottable.

Definition at line 19542 of file qcustomplot.cpp.

References mLowerQuartile, mMaximum, mMedian, mMinimum, mOutliers, mUpperQuartile, QCPAbstractPlottable::sdBoth, QCPAbstractPlottable::sdNegative, and QCPAbstractPlottable::sdPositive.

double key ( ) const

inline

Definition at line 2937 of file qcustomplot.h.

Referenced by setKey().

double lowerQuartile ( ) const

inline

Definition at line 2939 of file qcustomplot.h.

double maximum ( ) const

inline

Definition at line 2942 of file qcustomplot.h.

double median ( ) const

inline

Definition at line 2940 of file qcustomplot.h.

QPen medianPen ( ) const

inline

Definition at line 2948 of file qcustomplot.h.

double minimum ( ) const

inline

Definition at line 2938 of file qcustomplot.h.

QVector<double> outliers ( ) const

inline

Definition at line 2943 of file qcustomplot.h.

QCPScatterStyle outlierStyle ( ) const

inline

Definition at line 2949 of file qcustomplot.h.

double selectTest	(	const QPointF &	pos,
		bool	onlySelectable,
		QVariant *	details = `0`
	)		const

virtual

This function is used to decide whether a click hits a layerable object or not.

pos is a point in pixel coordinates on the QCustomPlot surface. This function returns the shortest pixel distance of this point to the object. If the object is either invisible or the distance couldn't be determined, -1.0 is returned. Further, if onlySelectable is true and the object is not selectable, -1.0 is returned, too.

If the object is represented not by single lines but by an area like a QCPItemText or the bars of a QCPBars plottable, a click inside the area should also be considered a hit. In these cases this function thus returns a constant value greater zero but still below the parent plot's selection tolerance. (typically the selectionTolerance multiplied by 0.99).

Providing a constant value for area objects allows selecting line objects even when they are obscured by such area objects, by clicking close to the lines (i.e. closer than 0.99*selectionTolerance).

The actual setting of the selection state is not done by this function. This is handled by the parent QCustomPlot when the mouseReleaseEvent occurs, and the finally selected object is notified via the selectEvent/deselectEvent methods.

details is an optional output parameter. Every layerable subclass may place any information in details. This information will be passed to selectEvent when the parent QCustomPlot decides on the basis of this selectTest call, that the object was successfully selected. The subsequent call to selectEvent will carry the details. This is useful for multi-part objects (like QCPAxis). This way, a possibly complex calculation to decide which part was clicked is only done once in selectTest. The result (i.e. the actually clicked part) can then be placed in details. So in the subsequent selectEvent, the decision which part was selected doesn't have to be done a second time for a single selection operation.

You may pass 0 as details to indicate that you are not interested in those selection details.

See Also: selectEvent, deselectEvent, QCustomPlot::setInteractions

Implements QCPAbstractPlottable.

Definition at line 19378 of file qcustomplot.cpp.

References QCPRange::contains(), mKey, QCPAbstractPlottable::mKeyAxis, mLowerQuartile, mMaximum, mMinimum, QCPLayerable::mParentPlot, QCPAbstractPlottable::mSelectable, mUpperQuartile, QCPAbstractPlottable::mValueAxis, mWidth, QCPAbstractPlottable::pixelsToCoords(), and QCustomPlot::selectionTolerance().

void setData	(	double	key,
		double	minimum,
		double	lowerQuartile,
		double	median,
		double	upperQuartile,
		double	maximum
	)

Sets all parameters of the statistical box plot at once.

See Also: setKey, setMinimum, setLowerQuartile, setMedian, setUpperQuartile, setMaximum

Definition at line 19293 of file qcustomplot.cpp.

References setKey(), setLowerQuartile(), setMaximum(), setMedian(), setMinimum(), and setUpperQuartile().

void setKey ( double key )

Sets the key coordinate of the statistical box.

Definition at line 19213 of file qcustomplot.cpp.

References key(), and mKey.

Referenced by clearData(), and setData().

void setLowerQuartile ( double value )

Sets the parameter "lower Quartile" of the statistical box plot. This is the lower end of the box. The lower and the upper quartiles are the two statistical quartiles around the median of the sample, they contain 50% of the sample data.

See Also: setUpperQuartile, setPen, setBrush, setWidth

Definition at line 19236 of file qcustomplot.cpp.

References mLowerQuartile.

Referenced by clearData(), and setData().

void setMaximum ( double value )

Sets the parameter "maximum" of the statistical box plot. This is the position of the upper whisker, typically the maximum measurement of the sample that's not considered an outlier.

See Also: setMinimum, setWhiskerPen, setWhiskerBarPen, setWhiskerWidth

Definition at line 19271 of file qcustomplot.cpp.

References mMaximum.

Referenced by clearData(), and setData().

void setMedian ( double value )

Sets the parameter "median" of the statistical box plot. This is the value of the median mark inside the quartile box. The median separates the sample data in half (50% of the sample data is below/above the median).

See Also: setMedianPen

Definition at line 19248 of file qcustomplot.cpp.

References mMedian.

Referenced by clearData(), and setData().

void setMedianPen ( const QPen & pen )

Sets the pen used for drawing the median indicator line inside the statistical box.

Definition at line 19350 of file qcustomplot.cpp.

References mMedianPen, and QCPAbstractPlottable::pen().

Referenced by QCPStatisticalBox().

void setMinimum ( double value )

Sets the parameter "minimum" of the statistical box plot. This is the position of the lower whisker, typically the minimum measurement of the sample that's not considered an outlier.

See Also: setMaximum, setWhiskerPen, setWhiskerBarPen, setWhiskerWidth

Definition at line 19224 of file qcustomplot.cpp.

References mMinimum.

Referenced by clearData(), and setData().

void setOutliers ( const QVector< double > & values )

Sets a vector of outlier values that will be drawn as scatters. Any data points in the sample that are not within the whiskers (setMinimum, setMaximum) should be considered outliers and displayed as such.

See Also: setOutlierStyle

Definition at line 19283 of file qcustomplot.cpp.

References mOutliers.

Referenced by clearData().

void setOutlierStyle ( const QCPScatterStyle & style )

Sets the appearance of the outlier data points.

See Also: setOutliers

Definition at line 19360 of file qcustomplot.cpp.

References mOutlierStyle.

Referenced by QCPStatisticalBox().

void setUpperQuartile ( double value )

Sets the parameter "upper Quartile" of the statistical box plot. This is the upper end of the box. The lower and the upper quartiles are the two statistical quartiles around the median of the sample, they contain 50% of the sample data.

See Also: setLowerQuartile, setPen, setBrush, setWidth

Definition at line 19260 of file qcustomplot.cpp.

References mUpperQuartile.

Referenced by clearData(), and setData().

void setWhiskerBarPen ( const QPen & pen )

Sets the pen used for drawing the whisker bars (Those are the lines parallel to the key axis at each end of the whisker backbone).

See Also: setWhiskerPen

Definition at line 19342 of file qcustomplot.cpp.

References mWhiskerBarPen, and QCPAbstractPlottable::pen().

Referenced by QCPStatisticalBox().

void setWhiskerPen ( const QPen & pen )

Sets the pen used for drawing the whisker backbone (That's the line parallel to the value axis).

Make sure to set the pen capStyle to Qt::FlatCap to prevent the whisker backbone from reaching a few pixels past the whisker bars, when using a non-zero pen width.
