#include <qcustomplot.h>

Inheritance diagram for QCPGrid:

Collaboration diagram for QCPGrid:

Public Member Functions
	QCPGrid (QCPAxis *parentAxis)

bool	subGridVisible () const

bool	antialiasedSubGrid () const

bool	antialiasedZeroLine () const

QPen	pen () const

QPen	subGridPen () const

QPen	zeroLinePen () const

void	setSubGridVisible (bool visible)

void	setAntialiasedSubGrid (bool enabled)

void	setAntialiasedZeroLine (bool enabled)

void	setPen (const QPen &pen)

void	setSubGridPen (const QPen &pen)

void	setZeroLinePen (const QPen &pen)

Public Member Functions inherited from QCPLayerable
	QCPLayerable (QCustomPlot plot, QString targetLayer=QString(), QCPLayerable parentLayerable=0)

	~QCPLayerable ()

bool	visible () const

QCustomPlot *	parentPlot () const

QCPLayerable *	parentLayerable () const

QCPLayer *	layer () const

bool	antialiased () const

void	setVisible (bool on)

Q_SLOT bool	setLayer (QCPLayer *layer)

bool	setLayer (const QString &layerName)

void	setAntialiased (bool enabled)

virtual double	selectTest (const QPointF &pos, bool onlySelectable, QVariant *details=0) const

bool	realVisibility () const

Protected Member Functions
virtual void	applyDefaultAntialiasingHint (QCPPainter *painter) const

virtual void	draw (QCPPainter *painter)

void	drawGridLines (QCPPainter *painter) const

void	drawSubGridLines (QCPPainter *painter) const

Protected Member Functions inherited from QCPLayerable
virtual void	parentPlotInitialized (QCustomPlot *parentPlot)

virtual QCP::Interaction	selectionCategory () const

virtual QRect	clipRect () const

virtual void	selectEvent (QMouseEvent event, bool additive, const QVariant &details, bool selectionStateChanged)

virtual void	deselectEvent (bool *selectionStateChanged)

void	initializeParentPlot (QCustomPlot *parentPlot)

void	setParentLayerable (QCPLayerable *parentLayerable)

bool	moveToLayer (QCPLayer *layer, bool prepend)

void	applyAntialiasingHint (QCPPainter *painter, bool localAntialiased, QCP::AntialiasedElement overrideElement) const

Protected Attributes
bool	mSubGridVisible

bool	mAntialiasedSubGrid

bool	mAntialiasedZeroLine

QPen	mPen

QPen	mSubGridPen

QPen	mZeroLinePen

QCPAxis *	mParentAxis

Protected Attributes inherited from QCPLayerable
bool	mVisible

QCustomPlot *	mParentPlot

QPointer< QCPLayerable >	mParentLayerable

QCPLayer *	mLayer

bool	mAntialiased

Friends
class	QCPAxis

Additional Inherited Members
Signals inherited from QCPLayerable
void	layerChanged (QCPLayer *newLayer)

Detailed Description

Responsible for drawing the grid of a QCPAxis.

This class is tightly bound to QCPAxis. Every axis owns a grid instance and uses it to draw the grid lines, sub grid lines and zero-line. You can interact with the grid of an axis via QCPAxis::grid. Normally, you don't need to create an instance of QCPGrid yourself.

The axis and grid drawing was split into two classes to allow them to be placed on different layers (both QCPAxis and QCPGrid inherit from QCPLayerable). Thus it is possible to have the grid in the background and the axes in the foreground, and any plottables/items in between. This described situation is the default setup, see the QCPLayer documentation.

Definition at line 930 of file qcustomplot.h.

Constructor & Destructor Documentation

QCPGrid ( QCPAxis * parentAxis )

Creates a QCPGrid instance and sets default values.

You shouldn't instantiate grids on their own, since every QCPAxis brings its own QCPGrid.

Definition at line 3673 of file qcustomplot.cpp.

References QCPLayerable::setAntialiased(), setAntialiasedSubGrid(), setAntialiasedZeroLine(), setPen(), setSubGridPen(), setSubGridVisible(), and setZeroLinePen().

Member Function Documentation

bool antialiasedSubGrid ( ) const

inline

Definition at line 946 of file qcustomplot.h.

bool antialiasedZeroLine ( ) const

inline

Definition at line 947 of file qcustomplot.h.

void applyDefaultAntialiasingHint ( QCPPainter * painter ) const

protectedvirtual

Implements QCPLayerable.

Definition at line 3754 of file qcustomplot.cpp.

References QCP::aeGrid, QCPLayerable::applyAntialiasingHint(), and QCPLayerable::mAntialiased.

Referenced by drawGridLines().

void draw ( QCPPainter * painter )

protectedvirtual

Implements QCPLayerable.

Definition at line 3764 of file qcustomplot.cpp.

References drawGridLines(), drawSubGridLines(), mParentAxis, and mSubGridVisible.

void drawGridLines ( QCPPainter * painter ) const

protected

void drawSubGridLines ( QCPPainter * painter ) const

protected

Definition at line 3853 of file qcustomplot.cpp.

References QCP::aeSubGrid, QCPLayerable::applyAntialiasingHint(), QCPAxisRect::bottom(), QCPAxis::coordToPixel(), QCPPainter::drawLine(), QCPAxisRect::left(), mAntialiasedSubGrid, QCPAxis::mAxisRect, mParentAxis, mSubGridPen, QCPAxis::mSubTickVector, QCPAxis::orientation(), QCPAxisRect::right(), QCPPainter::setPen(), and QCPAxisRect::top().

Referenced by draw().

QPen pen ( ) const

inline

Definition at line 948 of file qcustomplot.h.

Referenced by setPen(), setSubGridPen(), and setZeroLinePen().

void setAntialiasedSubGrid ( bool enabled )

Sets whether sub grid lines are drawn antialiased.

Definition at line 3701 of file qcustomplot.cpp.

References mAntialiasedSubGrid.

Referenced by QCPGrid().

void setAntialiasedZeroLine ( bool enabled )

Sets whether zero lines are drawn antialiased.

Definition at line 3709 of file qcustomplot.cpp.

References mAntialiasedZeroLine.

Referenced by QCPGrid().

void setPen ( const QPen & pen )

Sets the pen with which (major) grid lines are drawn.

Definition at line 3717 of file qcustomplot.cpp.

References mPen, and pen().

Referenced by QCPGrid().

void setSubGridPen ( const QPen & pen )

Sets the pen with which sub grid lines are drawn.

Definition at line 3725 of file qcustomplot.cpp.

References mSubGridPen, and pen().

Referenced by QCPGrid().

void setSubGridVisible ( bool visible )

Sets whether grid lines at sub tick marks are drawn.

See Also: setSubGridPen

Definition at line 3693 of file qcustomplot.cpp.

References mSubGridVisible, and QCPLayerable::visible().

Referenced by QCPGrid().

void setZeroLinePen ( const QPen & pen )

Sets the pen with which zero lines are drawn.

Zero lines are lines at value coordinate 0 which may be drawn with a different pen than other grid lines. To disable zero lines and just draw normal grid lines at zero, set pen to Qt::NoPen.

Definition at line 3736 of file qcustomplot.cpp.

References mZeroLinePen, and pen().

Referenced by QCPAxisRect::QCPAxisRect(), and QCPGrid().

QPen subGridPen ( ) const

inline

Definition at line 949 of file qcustomplot.h.

bool subGridVisible ( ) const

inline

Definition at line 945 of file qcustomplot.h.

QPen zeroLinePen ( ) const

inline

Definition at line 950 of file qcustomplot.h.
